Andrew D Beckman, 424564 Vista Meadows Dr, Batavia, OH 45103

7465279, Dec 16, 2008

Mar 31, 2004

10/815004

Andrew T. Beckman - Cincinnati OH, US
Rick D. Applegate - Florence KY, US
Michael E. Boehm - Cincinnati OH, US
William A. Garrison - Springdale OH, US
Douglas N. Ladd - Cincinnati OH, US

Ethicon Endo-Surgery, Inc. - Cincinnati OH

A61B 10/00

600566, 600567, 606170

A biopsy marker introduction assembly is configured for introduction through a specimen retrieval recess into a probe cutter lumen of a handheld breast biopsy handle. Advancing the cutter causes an extending deployment rod to distally translate within an introducer tube of the introduction assembly, pushing a biopsy marker out of a distal end of the probe at a surgical biopsy site. Thereby, the surgeon is able to position the probe and effect deployment of the marker even if using the other hand to position an imaging device such as an ultrasonic transceiver.

7670299, Mar 2, 2010

Mar 7, 2006

11/369587

Andrew T. Beckman - Cincinnati OH, US
Gwendolyn Perez Payne - Cincinnati OH, US
Lee Reichel - Springboro OH, US

Ethincon Endo-Surgery, Inc. - Cincinnati OH

A61B 10/00
A61B 17/32

600566, 600567, 606170

A medical device for severing and removing small amounts of internal tissue for biopsy sampling or other purposes is disclosed. Versions of the device may include a hollow probe having a piecing tip, a tissue receiving aperture and a vacuum lumen; a cutter within the probe having a cutting edge that moves past the tissue receiving aperture, and a cutter driver mechanism. A cutter for use with versions disclosed herein may include an angled cutting tip and a cutting edge having a concave grind. Versions of the device also may include an aspirator fluidly connected to the vacuum lumen, coordinated operation of the aspirator and the cutter driver mechanism, and a fluid management system. Versions described may be used for removing multiple samples of tissue during a single insertion of the probe proximate to a target tissue mass.

7678046, Mar 16, 2010

Mar 6, 2007

11/714267

William J. White - West Chester OH, US
Andrew T. Beckman - Cincinnati OH, US

Ethicon Endo-Surgery, Inc. - Cincinnati OH

A61B 1/06

600184

A seal assembly for permitting hand assisted laparoscopic procedures includes a seal cap having a seal positioned within a housing. The housing includes a lower seal ring having a track which supports an upper seal ring for relative rotational motion, wherein the seal is supported between the upper seal ring and the lower seal ring for rotation between an open orientation and a closed orientation. The track includes an inner upstanding annular wall and an outer upstanding annular wall connected by a base member. A ratchet mechanism controls motion of the upper seal ring relative to the lower seal ring. The ratchet mechanism includes a ratchet arm oriented to engage a ratchet surface and the ratchet surface is positioned between the inner upstanding annular wall and the outer upstanding annular wall.

7749161, Jul 6, 2010

Dec 1, 2006

11/607118

Andrew T. Beckman - Cincinnati OH, US
Carrie I. Fihe - Cincinnati OH, US
William J. White - West Chester OH, US

Ethicon Endo-Surgery, Inc. - Cincinnati OH

A61B 1/00

600208

A seal assembly for permitting hand assisted laparoscopic procedures includes a seal cap having an iris seal positioned within a housing. The housing includes a lower seal ring having a track which supports an upper seal ring for relative rotational motion, wherein the iris seal is supported between the upper seal ring and the lower seal ring for rotation between an open orientation and a closed orientation. The seal assembly also includes a retractor extending from the seal cap.

7766822, Aug 3, 2010

Mar 6, 2007

11/714268

William J. White - West Chester OH, US
Andrew T. Beckman - Cincinnati OH, US

Ethicon Endo Surgery, Inc. - Cincinnati OH

A61B 1/06

600184

A seal assembly for permitting hand assisted laparoscopic procedures includes a seal cap having a seal positioned within a housing. The housing includes a lower seal ring having a track which supports an upper seal ring for relative rotational motion, wherein the seal is supported between the upper seal ring and the lower seal ring for rotation between an open orientation and a closed orientation. The track includes an inner upstanding annular wall and an outer upstanding annular wall connected by a base member. A ratchet mechanism controls motion of the upper seal ring relative to the lower seal ring. The ratchet mechanism includes a ratchet arm oriented to engage a ratchet surface. The ratchet surface extends outwardly from a center of the seal assembly.

7806834, Oct 5, 2010

Mar 7, 2006

11/369588

Andrew T. Beckman - Cincinnati OH, US
Gwendolyn Perez Payne - Cincinnati OH, US
Lee Reichel - Springboro OH, US

Devicor Medical Products, Inc. - Cincinnati OH

A61B 10/00

600566, 600565, 600564

A medical device for severing and removing small amounts of internal tissue for biopsy sampling or other purposes is disclosed. Versions of the device may include a hollow probe having a piecing tip, a tissue receiving aperture and a vacuum lumen; a cutter within the probe having a cutting edge that moves past the tissue receiving aperture, and a cutter driver mechanism. A cutter for use with versions disclosed herein may include an angled cutting tip and a cutting edge having a concave grind. Versions of the device also may include an aspirator fluidly connected to the vacuum lumen, coordinated operation of the aspirator and the cutter driver mechanism, and a fluid management system. Versions described may be used for removing multiple samples of tissue during a single insertion of the probe proximate to a target tissue mass.

7819800, Oct 26, 2010

Dec 15, 2006

11/611193

Andrew T. Beckman - Cincinnati OH, US
Paul T. Franer - Cincinnati OH, US
Michael D. Cronin - Cincinnati OH, US

Ethicon Endo-Surgery, Inc. - Cincinnati OH

A61B 1/32

600208, 600201, 600204

A laparoscopic device assembly provides a tubular diaphragm twist seal that responds to a slight rotation of an actuating ring in a first direction by coupling a motor spring power assisted rotation of a bottom circumference of the twist seal achieves a pneumatic seal in an adjustable access channel defined by the state of the twist seal for maintaining an insufflated body cavity for a hand assisted laparoscopic surgical procedure. A slight rotation of the actuating ring in an opposite second direction releases compression spring energy and energy in the twisted state of the twist seal so that an upper circumference of the twist seal is allowed to open the adjustable access channel.

7867173, Jan 11, 2011

Aug 5, 2005

11/198558

John A. Hibner - Mason OH, US
Andrew T. Beckman - Cincinnati OH, US
Lee Reichel - Springboro OH, US
Chris W. Cicenas - Columbus OH, US
Luke C. Stonis - Columbus OH, US

Devicor Medical Products, Inc. - Cincinnati OH

A61B 10/00

600568

A biopsy device and method are provided for obtaining a tissue sample, such as a breast tissue biopsy sample. The biopsy device includes a disposable probe assembly with an outer cannula having a distal piercing tip, a cutter lumen, and a cutter tube that rotates and translates past a side aperture in the outer cannula to sever a tissue sample. The biopsy device also includes a reusable hand piece with an integral motor and power source to make a convenient, untethered control for use with ultrasonic imaging. The reusable hand piece incorporates a probe oscillation mode to assist when inserting the distal piercing tip into tissue. A straw stacking assembly is automatically positioned by the reusable hand piece to retract multiple samples with a single probe insertion as well as giving a visual indication to the surgeon of the number of samples that have been taken.
