Andrew C Ries Deceased300 Lakeside Ave, Seattle, WA 98144

6963780, Nov 8, 2005

Jan 31, 2002

10/061718

David A. Ruben - Mesa AZ, US
Andrew J. Ries - Lino Lakes MN, US
Juan G. Milla - Mesa AZ, US
Randy S. Roles - Crystal MN, US
Terry W. Bruneau - Anoka MN, US
Steve Craig Warren - Phoenix AZ, US
David W. Parkin - Phoenix AZ, US
John K. Day - Chandler AZ, US

Medtronic, Inc. - Minneapolis MN

A61N001/375

607 36, 607 37, 607 9, 607 4, 607 2, 439626, 429709, 4297331

An implantable medical device comprises an enclosure, a first plurality of electrical contacts disposed within the enclosure, at least a first electrical component secured within the enclosure, a second plurality of electrical contacts on the first electrical component, and a terminal array for providing electrical coupling between the first and second plurality of electrical contacts. The terminal array comprises a housing having a plurality of apertures therethrough, the housing having a first side and a second opposite side. Each of a plurality of conductive terminals is positioned within one of the plurality of apertures and has a first contact region proximate the first side of the housing and a second contact region proximate the second side of the housing. The first contact region is electrically coupled to one of the first plurality of electrical contacts, and the second contact region is electrically coupled to one of the second plurality of contacts.

2022024, Aug 4, 2022

Jan 10, 2022

17/571825

- Minneapolis MN, US
David A. Ruben - Mesa AZ, US
Andrew J. Ries - Lino Lakes MN, US
Chetan Patel - Phoenix AZ, US

G01L 9/00
B23K 26/20
H01L 23/522
H05K 5/06
H01L 23/00

Various embodiments of a pressure sensor assembly and an implantable medical device that includes such assembly are disclosed. The assembly includes a substrate having a via that extends through the substrate along a via axis between a first major surface and a second major surface of the substrate, a membrane disposed on the first major surface of the substrate and over the via, and a patterned metal layer disposed on a first major surface of the membrane, a portion of such layer including a first capacitor plate. The assembly further includes an integrated circuit disposed adjacent to the first major surface of the membrane and electrically connected to the metal layer. The integrated circuit includes a second capacitor plate disposed on or within a substrate of the integrated circuit. The first capacitor plate and the second capacitor plate form a variable capacitor disposed along the via axis.

2018033, Nov 22, 2018

May 17, 2018

15/982428

- Minneapolis MN, US
Mark E. HENSCHEL - Phoenix AZ, US
Andrew J. RIES - Lino Lakes MN, US
Rachel M. DAY - Tempe AZ, US
Kris A. PETERSON - Minneapolis MN, US

A61N 1/372
A61B 5/00

Systems, devices and methods are disclosed that include an antenna for an implantable medical device, the antenna including a passageway extending through the antenna windings of the antenna, the passageway providing a pathway for an electrical connector providing at least one electrical connection between a power source and electronic circuitry included within the implantable medical device.
