Arthur W Felix, 5617987 Strawberry Ln, Anderson, CA 96007

7937788, May 10, 2011

Jun 23, 2009

12/490166

Arthur R. Felix - Downey CA, US

Felix Manufacturing Company, Inc. - Compton CA

A47C 19/00
A47C 23/00

5201, 52821, 5285, 5286

A modular bed frame has ladder-like side frames with upper and lower side rails, and ladder-like end frames with upper and lower rails. The side and end frames telescopingly attach to the ends of upper and lower rounded corner rails. The insides of the side frames carry tubular upright fittings for increasing vertical rigidity. These fittings also provide upwardly opening tubular sleeves that receive right angle corner connectors on the ends of spaced apart and parallel horizontal slats that traverse the bed frame from end to end when assembled by a user. Separate upright rigid legs with feet on the bottom are slidably attached to downwardly opening tubular sleeves on the underside of the assembled frame structure to elevate the assembled bed foundation above the floor.

2007015, Jul 5, 2007

Jan 3, 2006

11/325402

Arthur Felix - Downey CA, US

A47C 19/00

005201000, 005131000

A modular bed frame has ladder-like side frames with upper and lower side rails, and ladder-like end frames with upper and lower rails. The side and end frames telescopingly attach to the ends of upper and lower rounded corner rails. The insides of the side frames carry tubular upright fittings for increasing vertical rigidity. These fittings also provide upwardly opening tubular sleeves that receive right angle corner connectors on the ends of spaced apart and parallel horizontal slats that traverse the bed frame from end to end when assembled by a user. Separate upright rigid legs with feet on the bottom are slidably attached to downwardly opening tubular sleeves on the underside of the assembled frame structure to elevate the assembled bed foundation above the floor.

4870711, Oct 3, 1989

Nov 14, 1988

7/271031

Arthur O. Felix - Downey CA

A47C 1900

5200R

A metal foundation for a bed comprises a modular system of components easily assembled without conventional fasteners. The assembly includes parallel tubular side frame members of rectangular cross-section, each having two L-shaped pieces interlocked lengthwise in a sliding fit. Vertical stiffening ribs spaced apart along the inside and outside faces of the rectangular side members add rigidity. A pair of parallel tubular rectangular end frame members similar to the side members are at opposite ends of the foundation. Four L-shaped and tubular corner connectors of rectangular cross-section provide sockets to slidably receive the ends of the side and end frame members at the corners of the foundation. Longitudinal and lateral inverted U-shaped cross-slats slidably fit into corresponding slots in the inside faces of the side and end frame members. Tapered vertical legs with casters slidably extend into flange openings at the corners of the corner connectors for holding the assembled foundation in a fixed position spaced above the floor.
