Brandon Matthew Stanton, 45912 Dominion Hill Dr, Cary, NC 27519

2013030, Nov 14, 2013

May 14, 2012

13/471164

Jeffrey Carl Britt - Cary NC, US
Michael P. Laughner - Cary NC, US
Brandon Stanton - Raleigh NC, US

CREE, INC. - Durham NC

F21V 9/00
F21V 5/04
F21V 21/00

362231, 36224902, 362235

Solid state (e.g., LED) lighting devices include multiple emitters mounted on or over a substrate comprising insulating material with conductive traces thereon, with various emitters being independently controllable with multiple pairs of anodes and cathodes that may be arranged on an opposite surface of the substrate than the emitters. Electrically conductive vias may be defined through the insulating substrate, and a molded lens may be provided over the substrate and emitters mounted thereon. Various combinations of independently controllable emitters or emitter groups may be provided, for example, a red emitter in combination with multiple blue shifted yellow (BSY) emitters, or separately controllable red, green, blue, and white (e.g., BSY) emitters.

2012018, Jul 26, 2012

Jul 20, 2011

13/187232

Jeffrey Carl Britt - Cary NC, US
Brandon Stanton - Raleigh NC, US
Yankun Fu - Raleigh NC, US

H05B 37/02
H01L 33/58

315291, 257 98, 257E3306

LED packages and related methods are provided. The LED packages can include a submount having a top and bottom surface and a plurality of top electrically conductive elements on the top surface of the submount. An LED can be disposed on one of the top electrically conductive elements. The LED can emit a dominant wavelength generally between approximately 600 nm and approximately 650 nm, and more particularly between approximately 610 nm and approximately 630 nm when an electrical signal is applied to the top electrically conductive elements. A bottom thermally conductive element can be provided on the bottom surface and is not in electrical contact with the top electrically conductive elements. A lens can be disposed over the LED. The LED packages can have improved lumen performances, lower thermal resistances, improved efficiencies, and longer operational lifetimes.
