Brian J Kaminski, 535036 SE 30Th Ave UNIT 37, Portland, OR 97202

6543405, Apr 8, 2003

Aug 8, 2001

09/924930

Anil Kumar Sachdev - Rochester Hills MI
Chin-Hsiu Li - Bloomfield Hills MI
Alexander Millerman - Bloomfield Hills MI
Yhu-Tin Lin - Rochester Hills MI
Brian Daniel Kaminski - Lake Orion MI
Thomas J. Klakulak - Washington MI

General Motors Corporation - Detroit MI

F02F 700

123195R

An automotive reciprocating engine design is disclosed preferably including an extruded cylinder bore block with cylinder bores and a surrounding coolant passage extending from a top flat surface to a bottom flat surface; a cast, closed bottom, open top crankcase with vertical walls having flat upper surfaces; and a stamped metal mid-plate interposed in sealing relationship between the bottom surface of the cylinder block and the flat top surfaces of the crankcase. The crankcase contains bearing supports for a crankshaft and the mid-plate contains holes for connecting rods attached to pistons in the cylinder bores. The design facilitates low cost manufacture of strong, light weight components and easier assembly of the engine, and permits flexible manufacture of a family of engines with different displacements by substitution of a cylinder block of different length or of different bore diameter.

6615901, Sep 9, 2003

Jun 11, 2001

09/878778

Brian D. Kaminski - Lake Orion MI
Douglas P. Leu - Wauseon OH
Norman L. Neuenschwander - Milford MI

General Motors Corporation - Detroit MI

B22D 3304

164137, 164340, 164 9, 164 11, 164332, 164333, 164368, 164369, 164370

An engine block mold package includes a barrel crankcase core having a plurality of barrels on each of which a respective cylinder bore liner is disposed. Each cylinder bore liner includes an inside diameter that is tapered along at least a portion of its length to match a draft angle present on the barrels to permit removal of the barrel crankcase core from a core box in which it is formed.

6945214, Sep 20, 2005

Dec 18, 2003

10/739435

Anil K. Sachdev - Rochester Hills MI, US
Brian D. Kaminski - Lake Orion MI, US
Alexander Millerman - Bloomfield Hills MI, US
Gary L. Jones - Farmington Hills MI, US
William H. Haverdink - Sterling Heights MI, US

General Motors Corporation - Detroit MI

F02F007/00

123195R

A modular engine assembly includes a cylinder bore block, a cylinder head disposed above the cylinder bore block, and a crankcase assembly disposed below the cylinder bore block. The crankcase assembly includes an upper carrier and a lower carrier each having a plurality of bearing portions therein being integral, unitary, and one-piece.

8079762, Dec 20, 2011

Aug 27, 2004

10/570259

Antonio Romero Fernandez - Vilassar De Mar, ES
Brian Daniel Kaminski - Lake Orion MI, US

F16C 33/14

384429, 384432, 419 27

Crankshaft bearing cap presenting on one of its faces a semi-cylindrical notch, formed by powder metallurgy with an iron powder blend molded by compaction and sintering, and partially infiltrated with Cu, being the area adjacent to the area around the notch, the one with highest Cu content. A method for manufacturing main bearing caps by infiltration of Cu including the steps of placing the molded cap so that the axis of the semi-cylindrical notch extends in a horizontal direction and the notch cavity is in the upwards position. Placing high Cu content tablets on the upper face of the cap and on the cylindrical arch and sintering of the cap and Cu tablets system.

4784534, Nov 15, 1988

Apr 13, 1987

6/037660

Brian D. Kaminski - Troy MI
Pulak Bandyopadhyay - Rochester Hills MI

General Motors Corporation - Detroit MI

B23D 4302
B23B 518

407 19

An improved cutting tooth configuration in which, unlike the conventional, straight line tool pattern with its constant tool rise, each tooth is incrementally advanced relative to the prior tooth by an amount that progressively decreases. This accounts for the variations in reaction force on the cutting teeth caused by workpiece deflections, so that the net thickness of material removed by each cutting tooth remains relatively constant. Instability and variation in the cutting force are thereby avoided, and tool wear is decreased.

5937804, Aug 17, 1999

Aug 22, 1997

8/916807

Brian Daniel Kaminski - Lake Orion MI

General Motors Corporation - Detroit MI

F02B 7522

123 547

An engine cylinder block assembly for a V-type engine wherein inner walls of the cylinder banks define a relatively oil free valley which is closed by a rigid valley cover to provide additional stiffness to the inside walls of the blocks, thereby stiffening the block against vibration and bending. The valley cover also includes sealed pockets for enclosing knock sensors mounted upon upwardly extending bosses in the bottom of the valley to both protect the knock sensors and permit their removal without requiring removal of the valley cover from the engine cylinder block. Oil entrainment due to pulsing air flows between crank chambers of the engine are reduced by providing openings in the valley floor between the front and rear crank chambers of the engine while the adjacent inner crank chambers are separated from direct connection with the valley.

4841820, Jun 27, 1989

Sep 2, 1988

7/239806

Brian D. Kaminski - Rochester Hills MI
Pulak Bandyopadhyay - Rochester Hills MI

General Motors Corporation - Detroit MI

B23B 100
B23B 518
B23D 4302

82 111

An improved cutting tooth configuration in which, unlike the conventional, straight line tool pattern with its constant tool rise, each tooth is incrementally advanced relative to the prior tooth by an amount that progressively decreases. This accounts for the variations in reaction force on the cutting teeth caused by workpiece deflections, so that the net thickness of material removed by each cutting tooth remains relatively constant. Instability and variation in the cutting force is thereby avoided, and tool wear is decreased.

4845763, Jul 4, 1989

Nov 6, 1987

7/118277

Pulak Bandyopadhyay - Rochester Hills MI
Dwight A. Blaser - Fraser MI
Brian D. Kaminski - Troy MI
Yong H. Lee - Troy MI

General Motors Corporation - Detroit MI

H04N 718
G06K 900

382 8

The disclosure reveals a computer vision technique to measure flank and crater wear of a single point cutting tool. This direct tool wear measurement method uses a microscope mounted camera to acquire an image of the tool. Special lighting of a face of the tool shows contrast of the wear region in the image. The image analysis is based on an interactive procedure utilizing a general purpose image processing system. A computer program calculates ten parameters to characterize flank and crater wear.
