Colin W Murphy, 4010970 Bluffside Dr UNIT 8, Studio City, CA 91604

6725610, Apr 27, 2004

Mar 21, 2001

09/814199

Colin Murphy - Seattle WA
Robert Mills - Seattle WA
Wei Lam - Seattle WA
David Landsburgh - Argyll, GB
Charles Phillips - Seattle WA

Exterior Research, LLC - Seattle WA

E06B 700

52 58, 522041, 522045, 527414, 5274515

A relatively high perm pliable moisture barrier material pliable sheet material exhibits a breathable perm value, e. g. , over 0. 4, that repels liquid water applied to a surface thereof and which permits water vapor to permeate therethrough in response to a pressure differential thereacross to preclude substantial condensation collection in the interior of said wall at the opening while providing a water barrier to liquid water applied thereto is applied to corners of the window opening in a wall as a plurality of corner seals with leg portions for application to the face of sheathing and leg portions for overlying the sill, jambs and head of the opening at the corners. Flanges may be included for sealing the sheet material to an interior vapor barrier material. Sill, jamb and head seals are applied over the corner seals and over the sill, head and jambs to completely seal the window opening with the sheet material. Weather resistant barrier material is then applied over or under the seals as are conventional metal flashing and sealant beads.

2014001, Jan 16, 2014

Jul 12, 2013

13/940855

Colin R. Murphy - Seattle WA, US

E04F 13/08

524891, 525821

A joiner clip for securing panels to a substrate is provided that includes a planar sheet of material that has a bottom portion terminating in outer edges. A pair of legs extends downward from the outer edges and terminating in a retaining shelf clip adapted to support a bottom edge of an inserted panel. Mounting holes form countersunk indents in the planar sheet that offsets the joiner clip from the substrate. A construction unit is also provided has such a joiner clip secured to a vertical stud substrate. At least inserted panel is supported in the retaining shelf clip of a first leg of the clip. A joint is readily formed between two inserted panels. Fasteners through an inserted panel secure the same to the clip and substrate. An additional siding strip is readily secured to the substrate below the pair of legs.

5709059, Jan 20, 1998

Apr 3, 1996

8/627029

Colin Murphy - Seattle WA
Robert Mills - Seattle WA
Mark Reichlin - Marysville WA
Steven Bunn - Seattle WA
Charles Phillips - Seattle WA

Exterior Research & Design, LLC - Seattle WA

F16B 1500

52410

A circular thin metal or thermoplastic disc stress plate has an annular stiffening rim and groove and a central opening. Three equilateral and symmetrically oriented elongated nail-like members depend from the plate at the rib and groove inclined in diverging relation relative to a vertical axis normal to and central the plate on a conical surface of revolution. The members extend radially beyond the perimeter of the stress plate projected onto the members forming an annular attachment region to a cementitious substrate significantly greater than the area subtended by the stress plate. Two or more than three members may be used in the alternative. The nail-like members have conical tips which may be any shape and blunt. The members preferably are circular cylinder steel, may be other transverse sectional shapes, and are driven individually or simultaneously into the substrate either through holes in the plate or penetrate the plate material by a power operated nail driving tool. The members may have heads of different shapes which are substantially recessed against the rib in the groove.

5882043, Mar 16, 1999

Oct 14, 1997

8/943292

Colin Murphy - Seattle WA
Robert Mills - Seattle WA

Exterior Research & Design, LLC - Seattle WA

E04D 1300

285 42

A square or circular apron formed of plastic coated disk-like sheet metal or fiber-metal reinforced synthetic material is bonded to a circular ring gasket having a surface conforming to the upper mating surface of an existing roof drain flange. Reinforcing rib depressions are formed in the apron outer region. The apron extends for a major radial extent beyond the periphery of the drain flange and with the gasket is clamped to the drain flange via existing bolt holes in the drain using stainless steel or bronze replacement bolts. Screws clamp the apron and the underlying roof membrane, which may be bonded to the apron to form a water tight seal, to the deck. A metal clamp ring may be used to clamp the apron and gasket to the drain flange. Various embodiments are disclosed.

2017005, Feb 23, 2017

Aug 17, 2016

15/239493

- Seattle WA, US
COLIN R. MURPHY - SEATTLE WA, US

E06B 1/62
E06B 7/14
B21D 28/00
E06B 1/70

A method for forming a sill pan is provided that includes the measurement of a width and length of an opening sill to be sealed. A piece of flexible sill pan material is cut based on the measured opening sill. Fold lines and cuts are created in the piece to form the sill pan. The resulting sill pan is readily formed to have at least one attribute of self-adherence, draining without shims, nail hole self-sealing, and provision of dams without resort to frame cutting.

2015007, Mar 19, 2015

Sep 16, 2014

14/487850

- Seattle WA, US
Colin R. Murphy - Seattle WA, US

E06B 1/70
B21D 5/16
E06B 7/14

72339

A method for forming a sill pan is provided that includes the measurement of a width and length of an opening sill to be sealed. A piece of flexible sill pan material is cut based on the measured opening sill. Fold lines and cuts are created in the piece to form the sill pan. The resulting sill pan is readily formed to have at least one attribute of self-adherence, draining without shims, nail hole self-sealing, and provision of dams without resort to frame cutting.
