Daniel L Weddle, 724201 Arbor Ln, Carrollton, TX 75010

5561960, Oct 8, 1996

Apr 18, 1995

8/423900

Larry A. Minnick - Indianapolis IN
Stephen L. Mitchell - Indianapolis IN
Daniel L. Weddle - Danville IN

The Exhibit House, Inc. - Indianapolis IN

E04B 208
E04H 100

52578

A modular wall panel system in which individual panels are constructed with a lightweight aluminum frame. In a preferred embodiment, the frame is substantially filled with a foam core material and decorative display surfaces are affixed to opposite sides thereof. One edge of the panels contains a plurality of specially shaped connector pins, while the opposite edge has a plurality of connector slots having a "dogbone" configuration. Therefore, a similar panel placed adjacent to the first panel may be mated thereto by engagement of the connector pins with respective connector slots in the other panel. The pins/slots are shaped and sized so that the connector pin may enter/exit the connector slot at either end of the dogbone but not in the center slot of the dogbone. Secure coupling with fast assembly/disassembly is thereby achieved, without tools or detachable components. Furthermore, the dogbone shape of the slot allows panels to be removed from either side.

5757779, May 26, 1998

Feb 4, 1997

8/796058

Charles D. Young - Plano TX
Daniel O. Weddle - Plano TX
Mel G. Bebee - Richardson TX

Rockwell International Corporation - Costa Mesa CA

H04J 116

370252

A automatic skywave communications system includes a control channel and one or more traffic channels for voice or data communications. The system automatically establishes and maintains traffic radio links. The system measures, reacts, signals and adapts system parameters.

5204855, Apr 20, 1993

Jan 9, 1991

7/639487

Melvin G. Bebee - Richardson TX
Bill C. Miller - Allen TX
Daniel O. Weddle - Plano TX
W. P. Werth - Richardson TX
C. David Young - Richardson TX

Rockwell International Corporation - Seal Beach CA

H04J 400

370 50

In a skywave adaptable communications network, the time required to initiate communications between two transceivers can often be an important factor where the propagation characteristics of signals at various frequencies vary drastically with time. The present invention improved upon the prior art by accepting the first frequency that it hears as a communication frequency when two nodes are attempting to communicate from a known list of frequencies to be transmitted at known times. The system then adaptively changes to better quality signals as these better quality signals are received, analyzed and compared with present working frequency signals.

4937822, Jun 26, 1990

Jun 27, 1989

7/371906

Daniel O. Weddle - Plano TX
Bill C. Miller - Allen TX
Melvin G. Bebee - Richardson TX
Charles D. Young - Richardson TX
Stephen W. Cable - Plano TX

Rockwell International Corporation - El Segundo CA

H04J 400

370124

An adaptive TDMA (time division multiple access) communication system is illustrated which dynamically maintains potentially different frequencies between nodes of the communication system using a process of communicating the quality of received signals between the nodes and storing this information so that an optimum frequency band can be selected whereby whenever signal quality deteriorates, an alternate frequency can be selected to provide continued communications. An embodiment of the system spans both high frequency (HF) and very high frequency (VHF) to establish the communications through atmospheric induced refractions (reflections) beyond line of sight between directly communicating nodes of the system. Further, the system uses frequency hopping both for signal transmission security and for node identification. When a node is traffic idle and also on a periodic maintenance basis, frequency bands other than the traffic frequency are analyzed for potential future use.

5359595, Oct 25, 1994

Dec 18, 1992

7/993495

Daniel O. Weddle - Plano TX
C. David Young - Richardson TX

Rockwell International Corporation - Seal Beach CA

H04J 100
H04J 400
H04B 1700

370 50

In the skywave adaptable communication network, the time required to initiate communications between two transceivers can often be an important factor where the propagation characteristics of signals at various frequencies may vary drastically with time. The present invention not only improves upon known prior art by accepting the first frequency that it hears as a communication frequency when two nodes are attempting to communicate from a known list of probe and default frequencies to be transmitted at known times, it uses an "announce and do" protocol to establish initial link-up and to change traffic frequencies or other system parameters once link-up has occurred to obtain coordination between both communicating nodes in a network of communicating nodes. The announce and do protocol requires multiple frequency announcements but the multi-frequency can be traffic frequency and a probe frequency or it can be multiple traffic frequencies whereby there is another communicating channel besides the channel which is involved in the changed system parameters. Once link-up has occurred, the probe signals are used to allow the system to then adaptively change the traffic frequencies to obtain better quality traffic signals, as these better quality probe signals are received, analyzed and compared with the quality of the present working frequency signals.

5204856, Apr 20, 1993

Jan 9, 1991

7/638956

Melvin G. Bebee - Richardson TX
Bill C. Miller - Allen TX
Daniel O. Weddle - Plano TX
C. David Young - Richardson TX

Rockwell International Corporation - Seal Beach CA

H04J 400

370 50

In a skywave adaptable communication network, the time required to initiate communications between two transceivers can often be an important factor where the propagation characteristics of signals at various frequencies may bary drastically with time. The present invention not only improves upon known prior art by accepting the first frequency that it hears as a communication frequency when two nodes are attempting to communicate from a known list of probe frequencies to be transmitted at known times, it initially uses predictive frequencies in probe signal format during the time that would later be used for traffic information after link-up has occurred where the predictive frequencies may be based on algorithms, experience or whatever. Once link-up has occurred, the probe signals are used to allow the system to then adaptively change to better quality signals as these better quality signals are received, analyzed and compared with present working frequency signals.
