Frank M Potucek, 743912 46Th Ave S, Saint Petersburg, FL 33711

4973211, Nov 27, 1990

Apr 15, 1988

7/181777

Frank R. Potucek - Palmetto FL

Star Fasteners International, Inc. - Savannah GA

F16B 1508

411452

A star shaped fastener having at least three fins radiating from a central core with the fin-included angle in a five finned embodiment being between 72 to 98 degrees which configuration reduces the fabricated material by 50% and increases the surface area by 15%-85% compared to a common round nail of equal radius.

4878794, Nov 7, 1989

Mar 15, 1988

7/168310

Frank R. Potucek - Palmetto FL

F16B 3500
F16B 3504

411395

A series of drywall screws are nested together and individually seated with a special driving tool after separation from one another. Each screw is hollow and has interior and exterior screw threads. One end of the screw has a hollow flat head and the body tapers downwardly to a bottom portion having a diameter less than half the diameter of the first end. A drill bit having an eccentric point drills a bore having a diameter greater than the diameter of the drill bit so that the bore operatively receives the screw.

4833906, May 30, 1989

May 11, 1988

7/192797

Frank R. Potucek - Palmetto FL

Star Fasteners International, Inc. - Savannah GA

B21B 1500
B21G 330

72206

A wire straightener and multiple preform rollers prepare a continuous length wire for further forming by multiple form rollers having multiple spaced apart notches formed in an annular edge of the rollers. Some notches skip a section of the wire to be headed, and other notches serve to form barbs in the wire. In a first embodiment, after the formed wire is fed to a gripper housing where the wire is cut to a predetermined length, the skipped section is punched to create the fastener head. In a second embodiment, the formed wire is cut and fed to a rotary heading machine.

4732564, Mar 22, 1988

Dec 23, 1986

6/945587

Frank R. Potucek - Clearwater FL
Edward J. Smith - Clearwater FL

Surgical Appliances, Inc. - Clearwater FL

A61C 300

433 50

Apparatus includes a mandible alignment device and a jaw pattern jig to prepare a one-piece metal dental implant for insertion into a patient's mouth. The alignment device has a central scissors member with a rear positioned thumb wheel controlling the longitudinal spread of the scissors blades. A front portion of a longitudinal angle adjustment member mounted over the scissors holds an anterior foot portion of a dental implant. A rod integral with the end of each scissors blade supports a housing holding a ramus member portion of a dental implant. After a pattern is determined by the alignment device, it is locked into the jaw pattern jig and the one-piece metal dental implant is bent to shape to substitute for the anterior foot and ramus members removed from the alignment device.

4755091, Jul 5, 1988

Jan 9, 1987

7/001693

Frank R. Potucek - Clearwater FL
Arthur G. Yeager - Jacksonville FL

Star Fasteners International, Inc. - Savannah GA

F16B 1508

411452

A star shaped fastener having at least five spaced vertical cups and edges about a central core with the included angle being 90. degree. reducing the fabricated material by 50% and increasing the surface area by 15% compared to a common round nail of equal radius. The holding power is significantly enhanced by compression laterally and vertically into cups, shoulders therein and/or a taper of less than 14. degree.

4899515, Feb 13, 1990

May 12, 1988

7/193424

Frank R. Potucek - Palmetto FL

American Rebar, Inc. - Midway GA

E04C 503

52738

A horizontally extending reinforcing bar having a central core in transverse cross-section exhibiting at least three radial fins projecting outwardly symmetrically from the center of the bar to its outer edge. Each pair of adjacent fins define a valley between them containing a pattern of raised surface area. Two in-line reinforcing bars are held together by a coupling device having a housing with multiple flexible inwardly projecting plates from grooves in an inner wall. The plates flex in the direction of insertion of a reinforcing bar and exert a force to prevent removal of the bar.

4800746, Jan 31, 1989

Oct 19, 1987

7/109988

Frank Potucek - Bradenton FL

B21D 3100
B21G 328
B21G 330

72372

A wire straightener, and multiple preform rollers prepare a continuous length wire for further forming with multiple form rollers having multiple spaced apart notches on an exterior surface edge of the rollers. The notches cause a section of the wire to be non-formed. After the formed wire is fed to a gripper housing where the wire is cut to a predetermined length, the non-formed section is punched to create the fastener head. The end section of the fastener opposite the head is tapered and the finished fastener is ejected from the machine.

4858457, Aug 22, 1989

May 12, 1988

7/192990

Frank R. Potucek - Palmetto FL

B21H 802

72187

A machine for making concrete reinforcing bars, known as rebars, from wire stock having a round cross section. A preform roller station cold works the round cross section of the wire stock into the shape of a polygon. A first form roller station cold works the polygonal cross section into a cross section having a central core and radial fin members extending therefrom. A second form roller station further reduces the diameter of the central core, and further increases the radial extent of the fin members. A third form roller station reduces the core still further, and again increases the radial extent of the fins, imparts shoulder members that provide an anti-longitudinal slip function at preselected intervals along the extent of the rebar, and roughens the rebar.
