Fred Y Brandon, 84731 Cindy Blair Way, Lexington, KY 40503

4994861, Feb 19, 1991

Jun 30, 1989

7/374519

Fred Y. Brandon - Lexington KY
James P. Harden - Lexington KY
Paul D. Horrall - Lexington KY
Troy A. Lee - Nicholasville KY
Kermit A. Meece - Lexington KY

International Business Machines Corporation - Armonk NY

G03G 1516
G03G 2100
B65H 3100

355274

A printing machine includes a charge neutralizing system for neutralizing static charge on sheets of material fed therethrough. The charge neutralizing system includes a grounded wire (47) located in proximity to the sheets for neutralizing charge on the sheets. The charge neutralizing system further includes a grounded conductive brush (81) mounted on a sheet deflector (61) so that one end of the brush (77) contacts sheets as they traverse a first sheet feed path (71) and the other end of the brush (79) contacts sheets are they are routed by the deflector to a second alternative sheet feed path (63). The grounded brush (81) further serves to decelerate the sheet as it exits the printing machine over the second sheet feed path (63).

5537136, Jul 16, 1996

Dec 7, 1993

8/163648

Fred Y. Brandon - Lexington KY
Curtis R. Droege - Richmond KY
James H. Powers - Lexington KY

Lexmark International, Inc. - Lexington KY

B41J 2175

347 87

An ink jet printer cartridge assembly including a cartridge body with at least one ink chamber from which ink flows to a print head. A standpipe in the ink chamber includes an opening therethrough for the flow of ink to the print head, and a filter cap is secured on the top of the standpipe to limit the introduction of air bubbles and particulate matter in the flow of ink toward the print head. The filter cap includes a mesh material formed into a dome-shaped configuration and an elastomeric material molded about the periphery of the mesh portion, with the elastomeric material being received around the top portion of the standpipe.

4162847, Jul 31, 1979

Oct 6, 1977

5/839856

Fred Y. Brandon - Boulder CO

International Business Machines Corporation - Armonk NY

G03G 1500
F27B 928

355 14

A heated fuser roller and backup roller fix toner on a sheet passing therebetween. These rollers are separated during nontoner fixing periods and normally closed for a predetermined early closure period prior to arrival of a sheet at the nip between the rollers. The immediate past history of fusing activity is monitored to determine whether the early roll closure is to be inhibited, a situation existing whenever the immediate past history indicates that steps must be taken to prevent backup roller overheating. The past history monitoring is performed by direct backup roller temperature sensing, timeout circuit operation or the like.

6283588, Sep 4, 2001

Dec 19, 2000

9/739273

Fred Young Brandon - Lexington KY
Robert Arnold Christiansen - Salvisa KY
Curtis Ray Droege - Belleville IL
Lawrence Russell Steward - Lexington KY
Gary Raymond Williams - Lexington KY

Lexmark International, Inc. - Lexington KY

B41J 2175

347 86

A print head having an ink reservoir therein is made by forming, in a one-shot plastic injection molding step, a rigid monolithic frame including high melt temperature material having an opening therein extending from a first side to a second side, and first and second bonding surfaces surrounding the opening and facing the first and second sides, respectively. First and second thin flexible films are adhesively secured to the first and second bonding surfaces, respectively. The adhesive material may be a hot melt adhesive or dry adhesive films pre-formed to the shape of the bonding surfaces. By securing the flexible films to the bonding surfaces adhesively, rather than by heat staking, it is not necessary to form the frame of different materials during two separate molding steps.

4253392, Mar 3, 1981

Apr 9, 1979

6/027951

Fred Y. Brandon - Lexington KY
Jack P. Chang - Boulder CO
William D. Clark - Longmont CO
Eugene G. Stahlberg - Boulder CO

International Business Machines Corporation - Armonk NY

B30B 300
B02C 1108
B60B 900
B21B 702

100155R

An electrophotographic copier machine with a roll fuser where one of the mating rolls is comprised of a thin outer shell which takes a variable taper so that a concave shape is produced under high humidity conditions and a relatively straight roller is produced under low humidity conditions. Means for changing the support at the roll ends is provided to produce the variable taper. End plugs can be moved axially inward at high humidity to provide support for the end portions of the normally concave roll and can be moved axially outwardly under low humidity such that no support is provided until the roll ends are flattened under the pressure of a mating roll.

5661510, Aug 26, 1997

Nov 22, 1994

8/343693

Fred Young Brandon - Lexington KY
Curtis Ray Droege - Centralia IL

Lexmark International, Inc. - Lexington KY

B41J 2175
B41J 2165

347 87

A cartridge for an ink-jet printer includes a nozzle plate having nozzles therein. A region around the nozzles is sealed when a maintenance cap is moved into contact with a surface of the cartridge surrounding the nozzle plate. Vent passages are provided in the cartridge body for venting the sealed region to the atmosphere. The vent passages are formed as grooves in a surface of the cartridge body, the open sides of the grooves being closed by an adhesive preform which attaches a tab circuit to the surface. One end of each passage vents to the atmosphere at a second surface of the cartridge body underneath a portion of the tab circuit which is not adhesively attached to the second surface. A second end of each vent passage extends into a region of the first surface that is not covered by the adhesive preform and tab circuit so that the vent passages communicate with the sealed region formed when the cap is moved into contact with the cartridge.

5831653, Nov 3, 1998

Aug 21, 1996

8/697151

Fred Young Brandon - Lexington KY
Curtis Ray Droege - Centralia IL
Bruce David Gibson - Lexington KY
Kenneth James Harshbarger - Lexington KY
James Harold Powers - Lexington KY
William Michael Toon - Lexington KY
John Dennis Zbrozek - Lexington KY

Lexmark International, Inc. - Lexington KY

B41J 2175

347 87

An ink-jet printer cartridge having a center reservoir chamber and two side reservoir chambers for holding inks of three different colors is provided with ink flow pathways of special configuration for connecting the reservoir chambers to exit ports at the print element. The ink flow pathways are provided with ridges extending along substantially their entire lengths so that air bubbles cannot completely block ink flow through the pathways. The ink flow pathways are disposed such that they have a vertical component of direction over their entire length and the pathways connecting the side reservoir chambers to exit ports include duct portions disposed at compound angles relative to the axes of the cartridge so that air bubbles, because of their buoyancy, will naturally tend to drift upwardly through the inclined ducts toward the reservoir chambers during normal usage, or drift toward the exit openings when the cartridge is inverted for priming. The duct portions of the ink flow pathways are generally trapezoidal in cross-section, the side walls intersecting the top wall at acute angles so that air bubbles cannot completely block the duct portions. The duct portions have end surfaces for directing air bubbles toward the reservoir chambers during priming, the end surfaces being end faces of plugs.

6243117, Jun 5, 2001

May 12, 1995

8/439912

Fred Young Brandon - Lexington KY
Robert Arnold Christiansen - Salvisa KY
Curtis Ray Droege - Belleville IL
Lawrence Russell Steward - Lexington KY
Gary Raymond Williams - Lexington KY

Lexmark International, Inc. - Lexington KY

B41J 2175

347 87

A print head having an ink reservoir therein is made by forming, in a one-shot plastic injection molding step, a rigid monolithic frame comprising high melt temperature material having an opening therein extending from a first side to a second side, and first and second bonding surfaces surrounding the opening and facing the first and second sides, respectively. First and second thin flexible films are adhesively secured to the first and second bonding surfaces, respectively. The adhesive material may be a hot melt adhesive or dry adhesive films pre-formed to the shape of the bonding surfaces. By securing the flexible films to the bonding surfaces adhesively, rather than by heat staking, it is not necessary to form the frame of different materials during two separate molding steps.
