Fred J Keiser, 803011 Hidden Mdw, Seguin, TX 78155

2003003, Feb 13, 2003

Jun 21, 2002

10/176932

Fred Keiser - Seguin TX, US

F16H047/08

475/091000

The invention is an infinitely variable ratio transmission that may include an input shaft connected to a carrier plate. The input shaft is disposed within the bore of a sun gear. At least one planetary gear is rotatably attached to the carrier plate. A ring gear is connected to an output shaft. The planetary gear is disposed between and meshed with the ring gear and the sun gear. A pump having a first and second gear enclosed within a housing is disposed about the input shaft. The second gear is attached to the sun gear. A pump oil pickup passageway connects an inlet port on the pump to a pump oil reservoir. A pump oil return passageway connects an outlet port of the pump to the reservoir. A control valve is provided to regulate fluid flow through the pump. Various clutch arrangements are disclosed to provide a reverse mode. In one embodiment of the invention a five piston variation pump is described in which the pistons are urged against an eccentric lobe mounted on the crankshaft of the transmission. A working fluid is charged into the piston cylinders to control the contact force applied by the pistons to the eccentric lobe, thereby controlling the rotational speed of the crankshaft.

5971880, Oct 26, 1999

Aug 7, 1998

9/130563

Fred Keiser - Seguin TX

F16H 4704

475 83

In a broad aspect, the invention is an infinitely variable ratio transmission that may include an input shaft connected to a carrier plate. The input shaft is disposed within the bore of a sun gear. At least one planetary gear is rotatably attached to the carrier plate. A ring gear is connected to an output shaft. The at least one planetary gear is disposed between and meshed with the ring gear and the sun gear. A pump having a first and second gear enclosed within a housing is disposed about the input shaft. The second gear is attached to the sun gear. A pump oil pickup passageway connects an inlet port on the pump to a pump oil reservoir. A pump oil return passageway connects an outlet port of the pump to the reservoir. A control valve is provided to regulate fluid flow through the pump. Various clutch arrangements are disclosed to provide a reverse mode.

6135909, Oct 24, 2000

Oct 25, 1999

9/426354

Fred Keiser - Seguin TX

F16H 4704

475107

In a broad aspect, the invention is an infinitely variable ratio transmission that may include an input shaft connected to a carrier plate. The input shaft is disposed within the bore of a sun gear. At least one planetary gear is rotatably attached to the carrier plate. A ring gear is connected to an output shaft. The at least one planetary gear is disposed between and meshed with the ring gear and the sun gear. A pump having a first and second gear enclosed within a housing is disposed about the input shaft. The second gear is attached to the sun gear. A pump oil pickup passageway connects an inlet port on the pump to a pump oil reservoir. A pump oil return passageway connects an outlet port of the pump to the reservoir. A control valve is provided to regulate fluid flow through the pump. Various clutch arrangements are disclosed to provide a reverse mode.

2016028, Sep 29, 2016

Mar 24, 2015

14/667335

David Keiser - Seguin TX, US
Fred Keiser - Seguin TX, US

F16K 5/06
F16J 15/02
F16J 15/12

A captivated seal assembly is disclosed. The seal assembly may include a metal seat shield, an annular elastomeric seal and a metal bonding ring. The metal bonding ring is preferably bonded to and fully encapsulated within the annular elastomeric seal. The composite metal bonding ring and elastomeric seal is contained in an annular recess formed in the metal seat shield. The metal bonding ring is secured to the metal seat shield, thereby retaining the elastomeric seal within the annular recess of the metal seat shield. The metal bonding ring may include a plurality of support pads for engagement with an annular back wall of the metal seat shield.
