Inventors:
Curtiss A. Grau - Duncan SC
George C. Mullis - Greer SC
Assignee:
Westinghouse Air Brake Company - Wilmerding PA
International Classification:
B61G 1100
Abstract:
A vehicular coupler comprises a head for coupling to an opposed, generally identical coupling head of a vehicle for mechanically connecting two vehicles together. Such coupler includes a beam member for connecting to the underside of one of such vehicles. A housing is slideably connected to the beam member and a cushioning device is connected to the coupling head. The coupling head has a rearward extension located in the housing. Primary shear bolts or pins extend through walls of the housing and into the rearward extension of the cushioning device. Secondary shear bolts or pins extend through the beam member and into the housing. Retaining bolts are secured to the housing and have upper portions located above an upper surface of the housing. A longitudinal relief area is provided in the beam member, with the upper portions of the retaining bolts being located in the relief area. The relief area terminates at a predetermined location in the beam member to provide a ledge for engagement with and retention of the upper portions of the retaining bolts when the primary and secondary shear bolts or pins are sheared in two and the coupling head and housing are moved forwardly relative to the beam member.
