Ian C Thorne, 5418 Melview Rdg, Norwich, VT 05055

2018026, Sep 13, 2018

Mar 5, 2018

15/911323

- Pearl River NY, US
Charles Culver Gidden Cooper - Arvada CO, US
Todd Michael Nelson - Louisville CO, US
Douglas Lorenz - Louisville CO, US
Ian Bradley Thorne - Thornton CO, US
Bryan Jeremy Schiffner - Westminster CO, US
Peter Zagone - Boulder CO, US
Liliya Gitarts - Thornton CO, US

Hunter Douglas, Inc. - Pearl River NY

H01M 2/10
H01M 2/20
E06B 9/322

A battery pack for use with a motorized architectural structure covering is illustrated. The battery pack includes a battery tube, and first and second end caps. The battery tube may include a valley portion located between first and second battery cavities for receiving first and second rows of batteries. The second end cap may include one or more projections (e.g., first and second tabs, handle, etc.) to facilitate removal of the battery pack from mounting clips associated with the motorized architectural structure covering. The removable, second end cap may include first and second release buttons extending into the valley portion. The release buttons may have a wider portion adjacent to the second end cap, and a narrower portion extending at least partially into the valley portion. The release buttons preferably include a tapered, for example, triangular, or trapezoidal shape, to extend into the valley portion for facilitating user engagement therewith.

2014011, May 1, 2014

Oct 31, 2013

14/068626

- Fort Collins CO, US
Ian Thorne - Thornton CO, US
Jered Harvey Dean - Arvada CO, US
Emanuel Guzman - Aurora CO, US
Sean Michael Cole - Denver CO, US
John R. Gardner - Parker CO, US
Scott Douglas Nelson - Denver CO, US

A61C 17/26

15 221

A toothbrush that includes a brushing attachment and a handle. The brushing attachment includes a main body portion with a hollow neck having an attachment opening and a head with a cleaning member opening, a drive shaft positioned in the neck, a cleaning member drive mechanism matingly engaged with gearing on the drive shaft, and a cleaning member extending through the cleaning member opening in the head and operatively associated with the cleaning member drive mechanism. The drive shaft includes a spline drive on one end and gearing on the opposite end. The handle includes a main body portion with a brushing attachment connection receiver that is at least partially received in the attachment opening. The brushing attachment connection receiver includes a recess defined therein that receives a drive hub with a grooved recess defined therein that receives the spline drive.

2014011, May 1, 2014

Oct 31, 2013

14/068733

- Fort Collins CO, US
Ian Thorne - Thornton CO, US
Jered Harvey Dean - Arvada CO, US
Emanuel Guzman - Aurora CO, US
Sean Michael Cole - Denver CO, US
John R. Gardner - Parker CO, US
Scott Douglas Nelson - Denver CO, US

A61C 17/22

15 221, 29428, 151591

A toothbrush that includes a brushing attachment and a handle is described. The brushing attachment includes a main body portion that includes a hollow neck and a head. The neck includes a skirt portion with an attachment opening and the head includes a cleaning member opening. The handle includes a main body portion that houses a motor, and a male attachment member extending upwardly from the main body portion that is at least partially received in the attachment opening in the brushing attachment. The male attachment member includes at least a first retention rib that is received in a first retention recess defined in the inner surface of the neck of the brushing attachment, and the inner surface of the neck includes a first retention lug extending outwardly therefrom that is positioned below the first retention rib.
