Jacob Boyd Rivers, 65Haslet, TX

4623489, Nov 18, 1986

Apr 2, 1985

6/719220

Jacob B. Rivers - Oklahoma City OK

C09F 510
C11B 304

260424

A method of refining edible oil which protects the oil from auto-oxidation and hydrolysis. The method of refining is of the type which includes a degumming stage where acid-water are blended with the oil to capture phosphatides in the oil and then separated from the oil to carry away the phosphatides. The method comprises deaerating the acid-water prior to blending with the oil so that as the acid-water removes phosphatides it also removes oxygen from the oil. Subsequent to the degumming stage, it is preferable that the processed oil be protected against any further contact with oxygen or water. If it is desired to remove all traces of oxygen an oxygen scavenger such as sodium sulfite can be added to the acid-water used in degumming.

4613410, Sep 23, 1986

Oct 7, 1983

6/540037

Jacob B. Rivers - Oklahoma City OK

B01D 116
B01D 310
C09F 512

203 39

A method and apparatus for distilling, especially vacuum refining and deodorizing edible oils and fats utilizing sheets of oil driven downwardly in a distiller with a vacuum source at its top. A nozzle includes pressure equalization chambers, cantilever adjustment screws, and a central drag sheet to produce longer lasting and more uniform thin oil sheets to be driven in the distiller. A continuous process deaerates, dehydrates, degums, bleaches, refines, removes tocopherol, deodorizes, and strips peroxides and hydroperoxides from raw oil in a series of isothermal stages utilizing driven sheet distillers. No stripping steam is used except in the stage which strips peroxides and hydroperoxides. The method produces valuable, pure products such as tocopherol and fractionated fatty acids. It is especially efficient in heat exchange and low in waste and pollution producing products.

4971660, Nov 20, 1990

Oct 11, 1988

7/255854

Jacob B. Rivers - The Village OK

B01D 310
C11B 312

203 40

A method and apparatus for distilling, especially vacuum refining and deodorizing edible oils and fats utilizing sheets of oil driven downwardly in a distiller with a vacuum source at its top. A nozzle includes pressure equalization chambers, cantilever adjustment screws, and a central drag sheet to produce longer lasting and more uniform thin oil sheets to be driven in the distiller. A continuous process deaerates, dehydrates, degums, bleaches, refines, removes tocopherol, deodorizes, and strips peroxides and hydroperoxides from raw oil in a series of isothermal stages utilizing driven sheet distillers. No stripping steam is used except in the stage which strips peroxides and hydro peroxides. The method produces valuable, pure products such as tocopherol and fractionated fatty acids. It is especially efficient in heat exchange and low in waste and pollution producing products.

4973430, Nov 27, 1990

Sep 7, 1989

7/404332

Jacob B. Rivers - Oklahoma City OK

C11C 312

260409

Improvements in determining and controlling a continuous hydrogenation process comprising the obtaining of viscosity operating curves and opacity operating curves for comparison to known hydrogen unsaturation curves and plasticity characteristics. With improved hydrogenation equipment for carrying out the continuous hydrogenation reaction in combination with deodorization and auto-oxidation prevention stations, the present invention provides an overall process and controls for precision hydrogenation of edible oils.

4871485, Oct 3, 1989

Jul 30, 1986

6/891771

Jacob B. Rivers - Oklahoma City OK

C11C 312
B01J 904

260409

Improvements in determining and controlling a continuous hydrogenation process comprising the obtaining of viscosity operating curves and opacity operating curves for comparison to known hydrogen unsaturation curves and plasticity characteristics. With improved hydrogenation equipment for carrying out the continuous hydrogenation reaction in combination with deodorization and autooxidation prevention stations, the present invention provides an overall process and controls for precision hydrogenation of edible oils.
