Implementing Ir Reflective Mask To Minimize Cte Mismatch Between Laminate And Pth Copper
US Patent:
2019036, Nov 28, 2019
Filed:
May 24, 2018
Appl. No.:
15/988397
Inventors:
- Armonk NY, US
Mark Plucinski - Toms River NJ, US
Timothy Tofil - Rochester MN, US
Joseph Kuczynski - North Port FL, US
Mark Plucinski - Toms River NJ, US
Timothy Tofil - Rochester MN, US
Joseph Kuczynski - North Port FL, US
International Classification:
H05K 3/34
G02B 5/08
B23K 1/005
G02B 5/08
B23K 1/005
Abstract:
A method and structure are provided for implementing manufacture of a printed circuit board (PCB) with one of an infrared (IR) reflective mask or a novel solder mask to minimize coefficient of thermal expansion (CTE) mismatch between PCB laminate and plated through hole (PTH) copper. At least one of an IR-reflective mask and a solder mask composition for use in IR reflow processes is created such that radiant heat is reflected away from the major portion of the PCB yet permitted to impinge upon the PTHs. The copper within the PTH expands due to radiant heating while the bulk laminate expansion is significantly reduced due to the reflected IR radiation. Consequently, the CTE mismatch is minimized and tensile strain of the copper in the PTH is reduced, providing enhanced reliability.
