John P Brainard Deceased16 Putnam Park Rd, Bethel, CT 06801

6353311, Mar 5, 2002

Jul 2, 1998

09/109595

John P. Brainard - Albuquerque NM, 87112
Robert D. Ney - Albuquerque NM, 87112-6615
Robert J. Ney - Albuquerque NM, 87112-6615

G01M 112

324 72, 324457, 73382 R

The design of Shaded Rotor devices to demonstrate the existence of a hypothetical Universal Particle Flux Field is presented. These devices should extract a measurable amount of energy from this Field. We believe the Universal Particle Flux Field can explain all invisible forces at a distance phenomena between masses, charged bodies, and magnetic materials. We propose that the Universal Particle Flux Field is a simultaneously convergent/divergent field, where the particle streams traverse to any point in the Universe from every other point in the Universe. The order of this Flux Field is a nearly perfect disorder, which is an order in itself. The strength of the gravitational component of this Field is conventionally denoted by âGâ. Two neutral masses immersed in such Flux Field will develop forces between them, which are consistent with Newtons Equation of Gravitation. This Field is also consistent with Electrostatic, and Magnetic Force Equations.

6555961, Apr 29, 2003

Sep 4, 2001

09/947106

John P. Brainard - Albuquerque NM
Robert J. Koss - Albuquerque NM

Sandia Corporation - Albuquerque NM

H01J 1730

313602

A high voltage surface flashover switch has a pair of electrodes spaced by an insulator. A high voltage is applied to an anode, which is smaller than the opposing, grounded, cathode. When a controllable source of electrons near the cathode is energized, the electrons are attracted to the anode where they reflect to the insulator and initiate anode to cathode breakdown.

7612541, Nov 3, 2009

Aug 7, 2007

11/835046

John P. Brainard - Albuquerque NM, US
Todd R. Christenson - Albuquerque NM, US

Sandia Corporation - Albuquerque NM

H02N 1/00

322 2A, 310309

A charge-pump voltage converter for converting a low voltage provided by a low-voltage source to a higher voltage. Charge is inductively generated on a transfer rotor electrode during its transit past an inductor stator electrode and subsequently transferred by the rotating rotor to a collector stator electrode for storage or use. Repetition of the charge transfer process leads to a build-up of voltage on a charge-receiving device. Connection of multiple charge-pump voltage converters in series can generate higher voltages, and connection of multiple charge-pump voltage converters in parallel can generate higher currents. Microelectromechanical (MEMS) embodiments of this invention provide a small and compact high-voltage (several hundred V) voltage source starting with a few-V initial voltage source. The microscale size of many embodiments of this invention make it ideally suited for MEMS- and other micro-applications where integration of the voltage or charge source in a small package is highly desirable.

7644841, Jan 12, 2010

Sep 22, 2006

11/525448

John P. Brainard - Albuquerque NM, US
Terry A. Gugliotta - Albuquerque NM, US
Beatrice A. Atchison - Del Rio TX, US

B65D 37/00

222211, 222622

A manually operated dispenser of the type containing a diaphragm at the bottom of the bottle, such that when the diaphragm is compressed a quantity of fluid is dispensed above the bottle through a spout. This invention uses a unique diaphragm shaped like a blister, that is integrated into the bottle bottom with a slide-pin allowing the blister diaphragm to move up and down, but not side to side. The diaphragm seals to the bottle bottom during dispensing, but when the diaphragm is substantially compressed, the seal self breaks as the diaphragm edge expands radially from the diaphragm axis over bumps on the bottle bottom allowing the diaphragm to refill. At the fluid output of the spout is a channel valve nozzle that channels the fluid into a stream when the fluid flows, but when the fluid is not being dispensed, prevents fluid from flowing back into the bottle.

2004011, Jun 24, 2004

Dec 24, 2002

10/328383

Robert Ney - Albuquerque NM, US
John Brainard - Albuquerque NM, US

H02N001/00

310/309000

One hundred thousand years ago a Caveman observed that a thrown stone always fell to the ground, and postulated that the ground mysteriously attracted the stone. One hundred thousand years later, and 315 years after Sir Isaac Newton published his Gravitational Force Equation, most People and Physicists still believe in this myth. It is well known that charged capacitor plates exhibit significant “attractive” forces between the plates, this invention is just converting this available short linear motion to a continuous circular motion. The Energy for the resulting motion is derived completely from the Cosmic Flux Field; the Electrostatic charge of the Rotor/Stator is not depleted!;The Ney-Brainard-Ney “osmic lux Field Theory”, and an Algorithm for calculating CF Turbine Rotor Torque is presented; they explain most of the mechanism of the “Invisible Forces at a Distance” (Gravitational, Electrostatic, and Magnetic). The Newton/Coulomb form of “Attraction” Force Equations are a great oversimplification of the Fundamental Physical Phenomena; it generally disregards the specific Attenuation/Impact Force of the Cosmic Flux traversing matter, which is the basis of all Cosmic Flux Forces!; The N/C Equation “blows up” to infinity when Centroids overlap and “d” in the denominator is zero. The Cosmic Flux Attenuation/Impact Forces of the Cosmic Flux paths traversing the Stators and Rotor must be Vectorially integrated, this will result in a net torque on the Rotor. In cases of relatively small Spherical mass diameters, at Astronomical distances apart, in Vacuum, of course Newton's approximation is quite accurate. The subject Cosmic Flux Electrostatic Turbine is rejected off hand by “conventional wisdom”, because each element of the Stator is perfectly symmetrical to the Rotor axis “hence no net Force/Torque can exist on the Rotor”. This conventional wisdom completely disregards the Fundamental Physical Phenomena.

6250798, Jun 26, 2001

Sep 21, 1998

9/158359

John Paul Brainard - Albuquerque NM
Hertha Ann Brainard - Albuquerque NM
Nicolas Charles Brainard - Albuquerque NM

G04B 1702

368180

This device projects slow moving light beams on the shadowed regions of a windowed room when the sun shines through the window. It includes a crystal-set (9) directly suspended from the bottom of a vertical rotor (14) of a motor (2) by a thread-like member (12). A small box (1), with attachment means to the window, supports the following interconnected electrical components: the motor (2) discussed above, a solar panel array (5), a capacitor (4), and a circuit (3). The capacitor is repeatedly charged slowly when the solar panel is exposed to sunlight, and discharged quickly by the circuit through the motor windings to occasionally pulse rotate the motor rotor about one turn. This occasional quick rotation activates and sustains the smooth and slow meandering rotation of the crystal-set about a vertical axis because of the loose thread-like member coupling between the motor rotor and crystal-set. The refracted and reflected light beams from the sunlit crystal-set produces a beautiful and entertaining light display of moving light beams that ebb and flow over the shaded surfaces of a sunlit room.

5675606, Oct 7, 1997

Mar 20, 1995

8/407455

John Paul Brainard - Albuquerque NM
Erskine John Thomas Burns - Albuquerque NM
Charles Hadley Draper - Albuquerque NM

The United States of America as represented by the United States
Department of Energy - Washington DC

H01J 724

31511171

An ion source which generates hydrogen ions having high atomic purity incorporates a solenoidal permanent magnets to increase the electron path length. In a sealed envelope, electrons emitted from a cathode traverse the magnetic field lines of a solenoid and a monocusp magnet between the cathode and a reflector at the monocusp. As electrons collide with gas, the molecular gas forms a plasma. An anode grazes the outer boundary of the plasma. Molecular ions and high energy electrons remain substantially on the cathode side of the cusp, but as the ions and electrons are scattered to the aperture side of the cusp, additional collisions create atomic ions. The increased electron path length allows for smaller diameters and lower operating pressures.

4529571, Jul 16, 1985

Oct 27, 1982

6/437081

Frank M. Bacon - Albuquerque NM
John P. Brainard - Albuquerque NM
James B. O'Hagan - Albuquerque NM
Robert J. Walko - Albuquerque NM

The United States of America as represented by the United States
Department of Energy - Washington DC

H01J 2702

376144

A single-ring magnetic cusp low gas pressure ion source designed for use in a sealed, nonpumped neutron generator utilizes a cathode and an anode, three electrically floating electrodes (a reflector behind the cathode, a heat shield around the anode, and an aperture plate), together with a single ring-cusp magnetic field, to establish and energy-filtering mechanism for producing atomic-hydrogen ions.
