John F Wegner, 86705 Main St, Prosser, WA 99350

6696174, Feb 24, 2004

Mar 22, 2002

10/104436

Lawrence D. Cercone - Pasadena CA
John W. Wegner - Monrovia CA
Franz Worth - Placerville CA
Steve R. Bazinet - El Monte CA

Air Logistics Corporation - Pasadena CA

B32B 1508

428626, 427140, 294021, 298971, 285 15, 138 97

A method for making a repair to a repair site of a structure made from at least a first tube and a second tube which are joined together with welds. The method includes cleaning and preparing the at least first tube and second tube tubes at the repair site for bonding with composite repair materials. Next, fiber-reinforced polymer composite repair materials are applied to the repair site. These composite materials include at least one elongate, composite tendon strip which is placed on the at least a first tube and a second tube such that the composite tendon strip bridges at least the first tube and a second tube, and a composite strip which is wrapped around and overlays the tendon strip with additional composite strips. The invention also provides a metal structure reinforced with a composite material repair site according to the method.

4513788, Apr 30, 1985

Nov 28, 1983

6/555371

Melvin D. Coker - Montebello CA
John W. Wegner - Deer Park TX

Koppl Company Inc. - Montebello CA

F16L 5510

138 89

A flange system for locking a plug in a pipeline flange. The flange system includes a flange with an axial passage for receiving a pipeline plug with a first annular groove. At least one radial passage for receiving a locking means and at least one locking means for engaging the first annular groove for locking the plug in place within the flange. Each such locking means is carried in a radial passage in the flange, the radial passage including a threaded driver bore and an unthreaded pin bore. Each such locking means includes a driver threadedly carried in the driver bore and a pin attached to the driver and carried in the pin bore. The locking means may include an arcuate locking collar carried by the pin, such that rotation of the driver causes the locking collar to be inserted into or retracted from the first annular groove of the plug, for locking and unlocking the plug in the flange.

4251479, Feb 17, 1981

Jun 28, 1979

6/052922

Adam Pecht - Downey CA
John F. Wegner - Los Angeles CA

Allied Record Company - Los Angeles CA

B29D 1700

264106

A method and apparatus for injection molding styrene phonograph records and the like. Through use of special fixtures and the careful control of time, temperature and pressure during the molding process in accordance with the method of the invention, the height, width, angle and side wall configuration of the groove of monophonic, sterophonic or quadraphonic record masters can be precisely replicated in the molded records, thereby enabling high volume production of injection molded styrene records of superior quality.
