6039041, Mar 21, 2000

May 19, 1999

9/314440

James T. Barth - Plano TX

Selkirk, Inc. - Dallas TX

F24C 300

126 85B

A sheet metal colinear-to-coaxial duct transition assembly for a fuel-fired, direct vent heating appliance is fabricated by providing a one-piece rectangular sheet metal plenum box having a rear wall with first and second circular openings therein, and an open front side. A separate rectangular front wall of the plenum box is also formed and has a circular opening therein. Prior to assembling the plenum box, a rearwardly projecting combustion air stub duct is secured to the rear plenum box wall at the first opening therein, and a forwardly projecting combustion air intake duct is secured to the front plenum box wall at the opening therein. Cooperating side edge portions and flange pockets on the front wall and the open side of the plenum box and then interlocked and crimped to complete the plenum box. A flue gas discharge duct is then extended rearwardly through the front air intake duct to cause a rear end portion of the flue gas discharge duct to project outwardly through the second opening in the rear plenum box wall, and secured to the rear wall so that a front portion of the flue gas discharge duct extends coaxially through the interior of the forwardly projecting air intake duct. The coaxial front ducts may then be connected to a coaxial vent termination assembly, and the rear duct portions may be connected to the colinear flue gas discharge and combustion air intake ducts of a fuel-fired, direct vent heating appliance.

5393260, Feb 28, 1995

Dec 10, 1993

8/166238

James T. Barth - Plano TX

Eljer Manufacturing, Inc. - Dallas TX

F23J 1302

454 44

A double wall vent pipe is provided which comprises a first tubular wall that is helically corrugated to form radially outermost ridges spiraled around the outside of the first tubular wall and corresponding first recesses spiraled between the outermost ridges. The vent pipe also comprises a second tubular wall slidably disposed in a concentric relationship with the first tubular wall. The second tubular wall is helically corrugated to form radially innermost ridges which spiral around the inside of the second tubular wall and corresponding second recesses spiral between the innermost ridges. The radially innermost ridges are oriented in a direction oblique to the orientation of the radially outermost ridges such that a space between the first wall and the second wall will be maintained within the first recesses and the second recesses regardless of any bending of the vent pipe.

5320520, Jun 14, 1994

Mar 18, 1993

8/033038

James T. Barth - Plano TX
Glenn W. Kowald - Carrollton TX

Eljer Industries, Inc. - Dallas TX

F23Q 232

431125

An inexpensive and easily maintained gas burner assembly achieves the manufacturing and maintenance advantages of the conventional sand pan burner design in addition to the heat output and fuel efficiency of more complex burner designs. The invention comprises a tray having a bottom wall and sidewalls defining an interior and an open top. A cover channel having a midsection segment and at least two downwardly depending flanges is adapted to fit in the interior of the tray to form a mixing chamber between the cover channel and the tray. The downwardly depending flanges are spaced away from the sidewalls of the tray to form gaps suitable for filling with a noncombustible granular substance, such as sand or crushed pumice stone. The cover channel additionally comprises at least one projection extending above the top segment and defining at least one burner port. The projection is preferably a longitudinal ridge defining a plurality of burner ports.

5328213, Jul 12, 1994

Dec 8, 1992

7/986791

James T. Barth - Plano TX

Eljer Industries, Inc. - Dallas TX

F16L 2100

285138

The adjustable pipe fitting of the invention has double walls in accordance with Type B standards established by the American National Standards Institute and Underwriters Laboratories. In the preferred embodiment, the invention comprises a main conduit having three sections which are rotatably coupled together. A branch conduit is securely connected to the main conduit so that fluid communication exists between the branch and main conduits. The branch conduit also comprises three sections which are rotatably coupled together. The main conduit sections and the branch sections are coupled together at oblique angles relative to their respective longitudinal axes to provide a means for adjusting the fitting to accommodate connector pipes having various angles and orientations.

6076862, Jun 20, 2000

Aug 24, 1998

9/138867

James T. Barth - Plano TX
Gerry J. Smith - Nampa ID

Selkirk, Inc. - Dallas TX

E04H 1702
F16L 3900

2851231

Each longitudinal section of a concentric direct vent duct structure for a fuel-fired appliance, such as a furnace, is formed using a tubular outer duct having an axially spaced pair of triangular stand-off frame members anchored therein, and a smaller diameter inner duct having an axially spaced pair of ramped external annular locking projections thereon. To assemble the concentric duct section, the inner duct is simply axially inserted into the outer duct. As the inner duct is inserted into the outer duct, a ramped annular side surface on the leading inner duct locking projection resiliently and radially outwardly deflects side wall portions of the stand-off frame members and then permits them to snap back to their original undeflected positions. When the inner duct reaches its operative position within the outer duct, facing radially extending side surfaces on the locking projections straddle the stand-off frame members and act as abutments therewith to prevent removal of the inserted inner duct from the outer duct in either axial direction. The cooperation between the inner duct locking projections and the resiliently deflectable side wall portions of the stand-off frame members thus provides for a convenient snap-locking installation of the inner duct within the outer duct.

5655514, Aug 12, 1997

Feb 26, 1996

8/607117

Glenn W. Kowald - Carrollton TX
James T. Barth - Plano TX

Eljer Manufacturing, Inc. - Dallas TX

F24C 300

126531

A fuel-fired fireplace insert has a compact combination heat exchanger/draft hood structure extending interiorly along its top side and opening outwardly through an upwardly extending flue gas outlet and a dilution air inlet disposed on a top front side portion of the insert. During insert operation, hot combustion gas generated within its fire box portion flows upwardly into the interior of the heat exchanger/draft hood structure, is cooled by room air entering the dilution air inlet, and is discharged through the flue gas outlet. At the same time, room air enters the insert through an opening on a lower front side thereof, is heated by being passed externally along the fire box and the combination heat exchanger/draft hood structure, and is then discharged from the insert back into the room through openings adjacent the dilution air opening.
