Kevin E Prosser, 62496 Hampton Lake Dr, Bluffton, SC 29910

2020041, Dec 31, 2020

Jun 27, 2019

16/454838

- Savannah GA, US
Kevin Prosser - Savannah GA, US

G08G 5/00
G08G 5/04
B64D 45/04
G07C 5/08

Avionics systems, aircraft, and methods are provided. An avionics system for an aircraft includes a trajectory modeling system and a Terrain Awareness Warning System (TAWS). The trajectory modeling system is programmed to determine a current performance capability of the aircraft and to generate potential escape data based on the current performance capability of the aircraft. The TAWS is programmed to generate a terrain margin using a TAWS algorithm based on the potential escape data and to generate a warning based on the terrain margin.

2020006, Feb 27, 2020

Aug 27, 2019

16/552606

- Savannah GA, US
Kevin Prosser - Savannah GA, US

Gulfstream Aerospace Corporation - Savannah GA

G05D 1/08
G08G 5/04

Avionics systems, aircraft, and methods are provided. An avionics system for a subject aircraft includes an intruder aircraft detection device and a processor. The processor is programmed to: identify an intruder aircraft using the intruder aircraft detection device; predict a future path of the intruder aircraft; estimate strength, size, and location characteristics of a wake vortex created by the intruder aircraft at future points in time along the future path; calculate a potential trajectory with potential positions of the subject aircraft at each of the future points in time; compare the potential positions with the strength, size, and location characteristics of the wake vortex at each of the future points in time to identify a wake conflict; and maneuver the subject aircraft based on the wake conflict.

2019015, May 23, 2019

Jan 17, 2019

16/250240

- Savannah GA, US
Kevin Prosser - Savannah GA, US

G08G 5/00
B64D 43/00
G05D 1/08
G08G 5/04
B64C 13/18
G08G 5/02

Systems and vehicle are provided. A vehicle system for a vehicle includes: a trajectory selection module configured to select a potential vehicle path relative to a current vehicle movement condition; a trajectory movement condition module configured to estimate a modeled movement condition of the vehicle along the potential vehicle path; a limit comparison module configured to determine whether the modeled movement condition violates vehicle limits; and a violation indicator module configured to generate an indication of impending violation.

2019014, May 16, 2019

Nov 14, 2018

16/191126

- Savannah GA, US
Kevin Prosser - Savannah GA, US

B64D 43/02
G07C 5/02
B64D 31/00

Systems and aircraft are provided. An avionics system includes a storage device and one or more data processors. The storage device stores instructions for monitoring an actual performance of the aircraft. The one or more data processors are configured to execute the instructions to: determine a first measured value of a flight characteristic of the aircraft at a first position of the aircraft; execute at least one flight maneuver between the first position and a second position of the aircraft; generate a predicted energy change between the first position and the second position based on the at least one flight maneuver and an energy state model; determine a second measured value of the flight characteristic of the aircraft at the second position; and generate an adjustment to the energy state model based on the first measured value, the second measured value, and the predicted energy change.

2019014, May 16, 2019

Nov 14, 2018

16/191103

- Savannah GA, US
Kevin Prosser - Savannah GA, US

G01P 5/16
G06F 17/50

Systems, methods, aircraft, non-transitory media, and memories are provided. An avionics system for an aircraft includes a storage device and one or more data processors. The storage device stores instructions for converting between airspeed types and the one or more data processors is configured to execute the instructions to: generate a calibrated airspeed of the aircraft; convert the calibrated airspeed to an actual true airspeed of the aircraft; determine an initial approximate relationship between the calibrated airspeed and a computed true airspeed as a function of a pressure altitude of the aircraft; generate an adjusted approximate relationship based on the actual true airspeed and the initial approximate relationship at a chosen pressure altitude; and estimate a future airspeed of the aircraft based on the adjusted approximate relationship and a future altitude.

2019014, May 16, 2019

Nov 14, 2018

16/191154

- Savannah GA, US
Kevin Prosser - Savannah GA, US

G08G 5/00
G01W 1/00
G06N 5/04

Systems, aircraft, and non-transitory media are provided. An avionics system for an aircraft includes a storage device and one or more data processors. The storage device stores instructions for monitoring an actual performance of the aircraft. The one or more data processors are configured to execute the instructions to: generate a lateral component and a longitudinal component of a measured moving air mass relative to the aircraft; generate a plurality of wind independent positions of the aircraft along a potential aircraft trajectory based on a prediction model; and generate a plurality of wind corrected positions of the aircraft based on the plurality of wind independent positions, on the lateral component, and on the longitudinal component.

2018027, Sep 27, 2018

Mar 27, 2017

15/470776

- Savannah GA, US
Kevin Prosser - Savannah GA, US

G05D 1/00
B64D 45/00
B64C 13/18
G08G 5/00

Systems and aircraft are provided. An avionics system for an aircraft includes: a trajectory selection module configured to select a potential aircraft path relative to a current aircraft flight condition; a trajectory flight condition module configured to estimate a modeled flight condition of the aircraft along the potential aircraft path; a limit comparison module configured to determine whether the modeled flight condition violates aircraft limits; and a violation indicator module configured to generate an indication of impending violation.
