Lin R HigleyJohn Day, OR

6372377, Apr 16, 2002

Mar 8, 1999

09/264116

Stanford R. Ovshinsky - Bloomfield Hills MI
Dennis A. Corrigan - Troy MI
Srinivasan Venkatesan - Southfield MI
Subhash K. Dhar - Bloomfield Hills MI
Arthur Holland - Bloomfield Hills MI
Donn Fillmore - Waterford MI
Lin Higley - Troy MI
Philippe Gow - Windsor CA
Ronald Himmler - Sterling Heights MI
Nick Karditsas - Lincoln Park MI
Kenneth Laming - Columbus MI
Anthony Osgood - Lake Orion MI

Ovonic Battery Company, Inc. - Troy MI

H01M 1002

429 66, 429 54, 429120, 429159, 429161, 429175

Mechanically and thermally improved rechargeable batteries and modules. The battery is prismatic in shape with an optimized thickness to width to height aspect ratio which provides the battery with balanced optimal properties when compared with prismatic batteries lacking this optimized aspect ratio. The optimized thickness, width and height allow for maximum capacity and power output, while eliminating deleterious side affects. The battery case design allows for unidirectional expansion which is readily compensated for by applying external mechanical compression counter to that direction. In the module, the batteries are bound within a module bundling/compression means under external mechanical compression which is optimized to balance outward pressure due to expansion and provide additional inward compression to reduce the distance between the positive and negative electrodes, thereby increasing overall battery power. Finally the batteries, modules and packs thereof can also include means for providing variable thermal insulation to at least that portion of the rechargeable battery system which is most directly exposed to ambient thermal conditions, so as to maintain the temperature of the rechargeable battery system within the desired operating range thereof under variable ambient conditions.

6689510, Feb 10, 2004

Sep 26, 2000

09/670155

Philippe Gow - Southfield MI
Anthony Osgood - Rochester Hills MI
Dennis A. Corrigan - Troy MI
Lin R. Higley - Troy MI
Marshall D. Muller - Farmington MI
Stanford R. Ovshinsky - Bloomfield Hills MI
Rajeev Puttaiah - Troy MI

Ovonic Battery Company, Inc. - Troy MI

H01M 642

429149, 429 99, 429163, 429159

A multi-cell monoblock battery in which a plurality of electrochemical cells are disposed in a battery case. The battery case includes one or more cell partitions which divide the interior of the case into a plurality of cell compartments that house the electrochemical cells. Preferably, one or more coolant channels are integrally formed with at least one of the cell partitions. The coolant channels may have inlets and outlets disposed in the walls of the battery case so as to provide a cross-flow cooling design.

6740446, May 25, 2004

Feb 22, 2002

10/081219

Dennis A. Corrigan - Troy MI
Lin Higley - Troy MI
Arthur Holland - Commerce Township MI
Marshall Muller - Farmington MI
John A. Smaga - Franklin MI

Ovonic Battery Company, Inc. - Troy MI

H01M 610

429152, 4292182, 429223

An electrochemical cell having electrodes that are arranged in a zigzag configuration with folds and creases. Additional electrodes may be inserted within the folds of the zigzag configuration. Preferably, the electrochemical cell is a prismatic cell.

6864013, Mar 8, 2005

Mar 19, 2003

10/391886

Philippe Gow - Southfield MI, US
Anthony Osgood - Rochester Hills MI, US
Dennis A. Corrigan - Troy MI, US
Lin R. Higley - Troy MI, US
Marshall D. Muller - Farmington MI, US
Stanford R. Ovshinsky - Bloomfield Hills MI, US
Rajeev Puttaiah - Troy MI, US

Chevron Texaco Technology Ventures, LLC - Troy MI

H01M010/50

429120, 429153

A multi-cell monoblock battery in which a plurality of electrochemical cells are disposed in a battery case. The battery case includes one or more cell partitions which divide the interior of the case into a plurality of cell compartments that house the electrochemical cells. Preferably, one or more coolant channels are integrally formed with at least one of the cell partitions. The coolant channels may have inlets and outlets disposed in the walls of the battery case so as to provide a cross-flow cooling design.

6878485, Apr 12, 2005

Apr 12, 2002

10/121279

Stanford R. Ovshinsky - Bloomfield Hills MI, US
Dennis A. Corrigan - Troy MI, US
Srinivasan Venkatesan - Southfield MI, US
Subhash K. Dhar - Bloomfield Hills MI, US
Arthur Holland - Bloomfield Hills MI, US
Donn Fillmore - Waterford MI, US
Lin Higley - Troy MI, US
Philippe Gow - Windsor, CA
Ronald Himmler - Sterling Heights MI, US
Nick Karditsas - Lincoln Park MI, US
Kenneth Laming - Columbus MI, US
Anthony Osgood - Lake Orion MI, US

Ovonic Battery Company, Inc. - Rochester Hills MI

H01M002/02
H01M002/12
H01M002/14
H01M002/30

429176, 429 53, 429120, 429129, 429180, 429181

Mechanically and thermally improved rechargeable batteries, modules and fluid-cooled battery pack systems. The battery is prismatic in shape with an optimized thickness to width to height aspect ratio which provides the battery with balanced optimal properties when compared with prismatic batteries lacking this optimized aspect ratio. The optimized thickness, width and height allow for maximum capacity and power output, while eliminating deleterious side affects. The battery case design allows for unidirectional expansion which is readily compensated for by applying external mechanical compression counter to that direction. In the module, the batteries are bound within a module bundling/compression means under external mechanical compression which is optimized to balance outward pressure due to expansion and provide additional inward compression to reduce the distance between the positive and negative electrodes, thereby increasing overall battery power. The fluid-cooled battery pack includes; 1) a battery-pack case having coolant inlet and outlet; 2) battery modules within the case such that the battery module is spaced from the case walls and from other battery modules to form coolant flow channels along at least one surface of the bundled batteries; and 3) at least one coolant transport means. The width of the coolant flow channels allows for maximum heat transfer.

6969567, Nov 29, 2005

Nov 6, 2000

09/707009

Lin R. Higley - Troy MI, US
Marshall D. Muller - Farmington MI, US
Dennis A. Corrigan - Troy MI, US

Texaco Ovonic Battery Systems, LLC - Troy MI

H01M006/42

429149, 429153, 429 99

A rechargeable multi-cell battery including a plurality of electrochemical cells. Each of the cells includes a gas port that allows passage of cell gases into and out of the cell but prevent passage of cell electrolyte out of the cell. The gas port may be a gas permeable membrane. The multi-cell batter may be a bipolar battery.

7217473, May 15, 2007

Sep 9, 2004

10/937023

Stanford R. Ovshinsky - Bloomfield Hills MI, US
Dennis A. Corrigan - Troy MI, US
Srinivasan Venkatesan - Southfield MI, US
Subhash K. Dhar - Bloomfield Hills MI, US
Arthur Holland - Bloomfield Hills MI, US
Donn Fillmore - Waterford MI, US
Lin Higley - Troy MI, US
Philippe Gow - Windsor, CA
Ronald Himmler - Sterling Heights MI, US
Nick Karditsas - Lincoln Park MI, US
Kenneth Laming - Columbus MI, US
Anthony Osgood - Lake Orion MI, US

Ovanic Battery Company, Inc. - Rochester Hills MI

H01M 2/12
H01M 10/50

429 62, 429 83, 429120

Mechanically and thermally improved rechargeable batteries, modules and fluid-cooled battery pack systems. The battery is prismatic in shape with an optimized thickness to width to height aspect ratio which provides the battery with balanced optimal properties when compared with prismatic batteries lacking this optimized aspect ratio. The fluid-cooled battery pack includes; 1) a battery-pack case having coolant inlet and outlet; 2) battery modules within the case such that the battery module is spaced from the case walls and from other battery modules to form coolant flow channels along at least one surface of the bundled batteries; and 3) at least one coolant transport means. The width of the coolant flow channels allows for maximum heat transfer.

7294431, Nov 13, 2007

Apr 14, 2004

10/824062

Rajeev Puttaiah - Troy MI, US
John Smaga - Franklin MI, US
Ronald Himmler - Sterling Heights MI, US
Lin R. Higley - Troy MI, US
Marshall D. Muller - Farmington Hills MI, US

Ovonic Battery Company, Inc. - Rochester Hills MI

H01M 2/00

429163, 429167

A battery having at least one group of electric power-generating elements each comprising at least a positive electrode, a negative electrode and a separator; and a battery case containing the group of electric power-generating elements. The battery case is formed from a mixture which includes a matrix material selected from the group consisting of plastics, polymers, resins or combinations thereof. The mixture further includes a thermally conductive, electrically insulating material distributed throughout the matrix material. The thermally conductive material has a thermal conductivity at least one order of magnitude higher than the thermal conductivity of the matrix material. The present invention also includes battery cases (lids and containers) used in making the batteries and formed of the mixture.
