Linh Ngoc Doan, 5314177 Woodgrove Dr, Van Buren Twp, MI 48111

7222910, May 29, 2007

Aug 30, 2005

11/162130

Linh Doan - Belleville MI, US
Marcus Oden - Canton MI, US
John Pinkerton - Canton MI, US
Lee Ho - Ann Arbor MI, US
Todd George - Chelsea MI, US

Ford Global Technologies, LLC - Dearborn MI

B60J 5/00

296153, 29618705, 296 109

An interior armrest for an automotive vehicle includes upper and lower horizontal walls and a channel-shaped lateral impact contactor joined to the upper horizontal walls by the means of shear planes. The lateral impact contactor has a number of wedge-shaped vertical interruptions which cooperate with the shear planes to produce a controlled collapse in the event of a lateral impact of an occupant of the vehicle against the armrest.

2012002, Jan 26, 2012

Jul 22, 2010

12/841221

Linh N. Doan - Belleville MI, US
James P. Holland - Brighton MI, US
Kenneth S. Laird - Canton MI, US
Stacy L. Swank - Auburn Hills MI, US
Jeffrey B. Crist - Sterling Heights MI, US
Warwick J. Smith - Grosse Pointe Woods MI, US
Aileen N. Barraza - Canton MI, US

FORD GLOBAL TECHNOLOGIES, LLC - Dearborn MI

B32B 3/10
B29C 45/14

428172, 264259

A plastic-molded automotive interior trim component has a curvilinear finished surface with a relatively flat portion and a relatively curved portion. A decorative film subcomponent has an outer surface and an inner surface, wherein at least the outer surface is pigmented with a desired color of the finished surface. Prior to incorporation into the plastic molded component, the decorative film subcomponent has a shape generally conforming to the curvilinear finished surface and is substantially smooth. A structural backing member is in-mold laminated with the decorative film subcomponent, wherein the structural backing member is formed by injection molding a backing material against the inner surface of the decorative film subcomponent in a mold having a film-receiving surface with a three-dimensional texture that receives the decorative film subcomponent. The texture shapes the decorative film subcomponent with an embossed pattern having a substantially uniform, undistorted appearance on at least part of the relatively flat portion and at least part of the relatively curved portion.

2021028, Sep 16, 2021

Mar 12, 2020

16/816371

- Dearborn MI, US
Emrah Tokyuerek - Koeln, DE
Linh Ngoc Doan - Belleville MI, US

Ford Global Technologies, LLC - Dearborn MI

F16B 2/24
B60J 5/04

A vehicle door assembly is disclosed herein. The vehicle door assembly includes a door. A trim panel has a mount that defines an aperture. A clip that includes a base is coupled to the door. A retainer is coupled to the base and is configured to extend through the aperture defined by the mount to an assembled position, the retainer has an upper portion that is coupled to a lower portion at a vertex to form a projection. A retention feature is coupled to the upper portion and has a ramp. A stop is coupled to the ramp and extends generally downward therefrom to the upper portion. The stop is configured to engage with a back side of the mount to generally prevent the movement of the retainer out of the aperture when the retainer is in the assembled position.

2021012, Apr 29, 2021

Oct 29, 2019

16/666873

- Dearborn MI, US
Linh Ngoc Doan - Belleville MI, US

Ford Global Technologies, LLC - Dearborn MI

G05D 1/00
B62D 1/183
B62D 5/04
B62D 15/02
B62D 1/185
B62D 1/181

A steering column for autonomous vehicles includes a powered actuator controlling rotation of a lower column, an inner column, and an upper column that is movable relative to the lower and inner columns. Rotation of the lower column relative to the upper column moves the upper column lengthwise. A powered lock rotatably interconnects the inner and lower columns when in a first position, and locks the inner column to a base when in a second position. In an autonomous mode, the upper column is stowed, the powered lock is in the first position, and the motor inhibits rotation of the lower column. In a manual mode, the upper column is extended, the powered lock is in the second position, and a sensor detects an angular position of the upper column.

2020034, Nov 5, 2020

May 3, 2019

16/402750

- Dearborn MI, US
Javier Polo - Köln, DE
Linh Ngoc Doan - Belleville MI, US

B60J 5/04
F16B 5/00
B60R 13/02

A doghouse retainer includes a body having an end wall incorporating a clip receiver and a sidewall having an ultrasonic heating concentration feature. A door assembly is provided including a door inner and a door trim panel incorporating such a doghouse retainer. A method of adjusting a gap between two components is also provided.

2020026, Aug 20, 2020

Feb 18, 2019

16/278516

- Dearborn MI, US
Bhavani S. Thota - Novi MI, US
Linh Ngoc Doan - Belleville MI, US
Ryan Mowery - Albion MI, US

F16B 37/00
B60R 13/02
F16B 5/02

A fastener boss includes a body having a receiving column. The receiving column includes a first section with a first wall thickness and a second section with a second wall thickness wherein the first wall thickness is greater than the second wall thickness. A motor vehicle component incorporating the fastener boss is also disclosed.

2020023, Jul 30, 2020

Jan 30, 2019

16/262415

- Dearborn MI, US
Linh Ngoc Doan - Belleville MI, US
Bhavani Thota - Novi MI, US

B60R 7/04

An apparatus is provided for holding an article in a motor vehicle. That apparatus includes a motor vehicle storage compartment having a receiver and a reversible insert held in the receiver. A storage system is also disclosed including a left-hand storage compartment including a first receiver, a right-hand storage compartment including a second receiver and a reversible insert configured for receipt in the first receiver and the second receiver.

2020022, Jul 16, 2020

Jan 11, 2019

16/245473

- Dearborn MI, US
Bhavani Thota - Novi MI, US
Steven Nicholas Fidh - Ann Arbor MI, US
Gary D. Mullen - Plymouth MI, US
Linh Ngoc Doan - Belleville MI, US

B60R 7/04
B60R 13/02
B60R 7/08

A apparatus includes a trim panel and a displaceable face pane. The trim panel includes a storage compartment and a guideway having a latching slot and a positioning rack. The displaceable face panel has a trunnion received for sliding movement along the guideway.
