Martin BernsteinBellingham, WA

5582515, Dec 10, 1996

May 4, 1995

8/434893

Frantisek L. Eisinger - Demarest NJ
Martin D. Bernstein - Bronx NY

Foster Wheeler Energy Corporation - Clinton NJ

F23C 1104

431 1

An acoustically pulsating burner assembly which includes an elongated outer tube, a fuel supply means located within the tube, and utilizes one or more integral axially adjustable Sondhauss thermoacoustic tubular elements to generate pulsations within the burner. The acoustic pulsations are generated inside the axially movable closed end tube element provided within the burner, and these vibrations promote more efficient combustion of the fuel so as to reduce undesired emissions in the combustion products. If desired, multiple thermoacoustic tubular elements of different lengths can be advantageously used to generate pulsations of different frequencies within the burner assembly. The burner assembly is located in a furnace windbox, and can be adapted for combusting gas, oil or particulate fuels such as coal.

3973621, Aug 10, 1976

Nov 27, 1974

5/527773

William James Bow - Morris Township NJ
Martin David Bernstein - Bronx NY

Foster Wheeler Energy Corporation - Livingston NJ

F28F 912
F28F 500

165 83

A heat exchanger in which a plurality of tubes are supported by tube sheets within a shell having inlet and outlet heads connected to its ends. One of the heads and tube sheets are secured directly to one end of the shell while the other tube sheet and head form a floating head assembly which is connected to the other end of the shell by an expansion joint to permit relative movement between the head assembly and the shell. A first heat exchange fluid is passed into the inlet head and through the tubes before discharging from the outlet head, and a second heat exchange fluid is passed through the shell in a heat exchange relation to the first heat exchange fluid. A load is applied to the head assembly in the direction of the shell to preload the tubes in compression, and movements of the head assembly relative to the shell in excess of a predetermined amount are prevented.
