Martin H Wieder, 64N8771 County Road X, Watertown, WI 53094

D467492, Dec 24, 2002

Mar 18, 2002

29/157405

Martin H. Wieder - Watertown WI

Martin Technology Group - Watertown WI

0805

D 8356

6612619, Sep 2, 2003

Jan 5, 1999

09/225788

Martin H. Wieder - Watertown WI, 53094

F16L 5500

285 23, 285 45, 285114, 285117, 285305

A quick coupler retention clip is disclosed for preventing an inadvertent disconnection of a quick coupler. The clip device includes a unitary clip having a first and a second end. The first end of the clip is of annular configuration so that the body of the coupler extends through the annular first end for anchoring the first end of the clip relative to the body. The second end of the clip is a C-shaped configuration to removably engage a groove defined between a collar and the body of the coupler. A strap extends between the first and second ends of the clip for securing the first and second ends of the clip together. The disconnection of the body from the port of the quick coupler is permitted only when the C-shaped second end is removed from engagement with the groove so that inadvertent disconnection of the body from the port is prevented.

2003008, May 1, 2003

Oct 3, 2002

10/264045

Martin Wieder - Watertown WI, US

F16L055/00

285/081000, 285/091000, 285/114000, 285/305000, 285/316000

A quick coupler retention clip is disclosed for preventing an inadvertent disconnection of a quick coupler. The clip device includes a unitary clip having a first and a second end. The first end of the clip is of annular configuration so that the body of the coupler extends through the annular first end for anchoring the first end of the clip relative to the body. The second end of the clip is a C-shaped configuration to removably engage a groove defined between a collar and the body of the coupler. A strap extends between the first and second ends of the clip for securing the first and second ends of the clip together. The disconnection of the body from the port of the quick coupler is permitted only when the C-shaped second end is removed from engagement with the groove so that inadvertent disconnection of the body from the port is prevented.

6312628, Nov 6, 2001

Dec 28, 1998

9/221544

Horst K. Wieder - Watertown WI
Martin Wieder - Watertown WI
Peter Strupp - Watertown WI

CITO Products, Inc. - Watertown WI

B29C 4573

264 3727

A method and system for controlling the temperature of a fluid cooled high temperature injection mold having fluid channels formed therein. A high temperature injection mold has an operating temperature above the boiling point of water. A flow of either elevated pressure or low pressure cooling water is passed through the fluid channels in the high temperature injection mold for a limited duration during the molding cycle to thereby reduce the temperature of the injection mold to a desired level. Elevated pressure cooling water is elevated to a pressure level such that the cooling water will remain in a liquid state while passing through the fluid channels. Low pressure cooling water is at a pressure level such that the cooling water enters the fluid channels in a liquid state and transitions to a vapor state within the fluid channels. The cooling water may be provided to the high temperature injection mold in a closed loop system, wherein cooling water which is treated to remove contaminants therefrom is stored in a cooling water supply tank. Used high temperature cooling water emerging from the fluid channels of the high temperature injection mold is preferably mixed with lower temperature cooling water from the cooling water supply tank before being returned to the cooling water supply tank.
