Michael D Coles, 71Akron, OH

7091635, Aug 15, 2006

Oct 20, 2004

10/970802

Michael L Gilliland - Kent OH, US
David B Finkenbinder - Ravenna OH, US
Michael Coles - Kent OH, US

Ametek, Inc. - Kent OH

H02K 9/06
H02K 5/20

310 62, 310 63, 74572, 482 54

A flywheel/motor assembly is disclosed that comprises a motor housing having a sidewall and an end wall extending substantially perpendicularly from the sidewall. The end wall enclose a motor assembly having a rotatable shaft extending therefrom. The motor housing has at least one air flow opening therethrough. A flywheel is coupled to the shaft, and includes a pulley side and a motor side opposite the pulley side, wherein the motor side is aligned substantially with the end wall and does not extend over the sidewall. A plurality of vanes are associated with the flywheel, wherein adjacent vanes form channels therebetween. A ring is coupled to the plurality of vanes and at least partially encloses the channels and forms exhaust ports away from the shaft. Rotation of the flywheel draws air through the motor housing's openings into the channels and out the exhaust ports. The pulley side may include balancing bores for receiving balancing material to balance the finished assembly.

7102266, Sep 5, 2006

Feb 8, 2005

11/054666

Michael Coles - Kent OH, US

Ametek, Inc. - Kent OH

H01R 39/38

310239, 310 88, 310233, 310220

A motor assembly includes a commutator having a shaft extending axially therefrom, a commutator end bracket assembly, and at least two brushes carried by the commutator end bracket assembly and in contact with the commutator. A seal is carried by either the commutator or the commutator end bracket assembly and has engaging contact with the other. The seal may be disposed on either or both sides of the commutator.

2003000, Jan 2, 2003

Jun 18, 2001

09/883627

Michael Coles - Kent OH, US
John Porter - Ravenna OH, US

Ametek, Inc.

H02K005/16
H02K007/08

310/090000, 310/085000, 310/088000

A motor assembly with improved sealing properties includes a motor having a rotatable shaft, a working air fan assembly carried by the shaft, the working air fan assembly moving air therethrough, and a sealed bearing interposed between the working air fan assembly, the sealed bearing having an inner ring rotatable with respect to an outer ring, and a seal carried by one of the rings, the seal frictionally contacting the other of the rings.

2003011, Jun 26, 2003

Jan 28, 2003

10/352456

Michael Coles - Kent OH, US
John Porter - Ravenna OH, US

Ametek, Inc.

F16J015/32

277/572000

A motor assembly with improved sealing properties includes a motor having a rotatable shaft, a working air fan assembly carried by the shaft, the working air fan assembly moving air therethrough, and a sealed bearing interposed between the working air fan assembly, the sealed bearing having an inner ring rotatable with respect to an outer ring, and a seal carried by one of the rings, the seal frictionally contacting the other of the rings

5987808, Nov 23, 1999

Jul 2, 1998

9/109151

Michael Coles - Kent OH

A01K 9700

43 55

A fish stringer for use in tournament fishing is provided having a weight indicator attached thereto which can be manually adjusted to indicate the weight of the fish attached to the stringer. A clip attached through the fish's gill and thereby fastens the fish to a suitable cord which attaches to a floating weight indicating device. The weight indicating device contains a number of disks bearing numbers which may be manually rotated to create a display of the weight of the fish. This device floats on the surface of the water and thereby allows a fisherman to efficiently locate the lightest fish held in his live well.

6309180, Oct 30, 2001

Aug 18, 2000

9/642297

Michael L. Gilliland - Kent OH
Robert A. Ciccarelli - Kent OH
Michael Coles - Kent OH

Ametek, Inc. - Kent OH

F04D 2944

4152082

A molded through-flow motor assembly has a motor housing, including a cup portion and a flange portion. The flange portion includes a plurality of ramp surfaces extending outwardly therefrom. The cup portion has a field retaining wall and guide rib extending inwardly therefrom on opposite sides of the housing. A diffuser plate is provided having a plurality of scalloped ramp surfaces on a first side thereof adjacent to a plurality of air inlet apertures which open into air chambers on the second side thereof. The field and armature portions of a motor assembly are mounted in the motor housing and the diffuser plate is fitted to the flange portion of the housing such that the ramp surfaces abut one another to form a continuous ramp surface from each air inlet aperture into the air chambers. A rotating fan member is mounted to the armature shaft and is housed within a shroud cover fitted to the motor housing. In operation, air is directed through the shroud cover by the rotating fan and into the air chambers by way of the air inlet apertures and ramp surfaces.

6037688, Mar 14, 2000

Feb 9, 1998

9/020718

Michael L. Gilliland - Kent OH
Robert A. Ciccarelli - Kent OH
Michael Coles - Kent OH

Ametek, Inc. - Kent OH

H02K 516

310 89

A molded through-flow motor assembly has a motor housing, including a cup portion and a flange portion. The flange portion includes a plurality of ramp surfaces extending outwardly therefrom. The cup portion has a field retaining wall and guide rib extending inwardly therefrom on opposite sides of the housing. A diffuser plate is provided having a plurality of scalloped ramp surfaces on a first side thereof adjacent to a plurality of air inlet apertures which open into air chambers on the second side thereof. The field and armature portions of a motor assembly are mounted in the motor housing and the diffuser plate is fitted to the flange portion of the housing such that the ramp surfaces abut one another to form a continuous ramp surface from each air inlet aperture into the air chambers. A rotating fan member is mounted to the armature shaft and is housed within a shroud cover fitted to the motor housing. In operation, air is directed through the shroud cover by the rotating fan and into the air chambers by way of the air inlet apertures and ramp surfaces.

5734214, Mar 31, 1998

Nov 9, 1995

8/554934

Michael L. Gilliland - Kent OH
Robert A. Ciccarelli - Kent OH
Michael Coles - Kent OH

Ametek, Inc. - Kent OH

H02K 516
H02K 906
H02K 504

310 89

A molded through-flow motor assembly has a motor housing, including a cup portion and a flange portion. The flange portion includes a plurality of ramp surfaces extending outwardly therefrom. The cup portion has a field retaining wall and guide rib extending inwardly therefrom on opposite sides of the housing. A diffuser plate is provided having a plurality of scalloped ramp surfaces on a first side thereof adjacent to a plurality of air inlet apertures which open into air chambers on the second side thereof. The field and armature portions of a motor assembly are mounted in the motor housing and the diffuser plate is fitted to the flange portion of the housing such that the ramp surfaces abut one another to form a continuous ramp surface from each air inlet aperture into the air chambers. A rotating fan member is mounted to the armature shaft and is housed within a shroud cover fitted to the motor housing. In operation, air is directed through the shroud cover by the rotating fan and into the air chambers by way of the air inlet apertures and ramp surfaces.
