Michael Edward Heaton, 634506 Landmark Dr, Rock Hill, SC 29732

2003001, Jan 30, 2003

Jul 26, 2001

09/915805

Michael Heaton - Rock Hill SC, US
William Buckner - Grosse Ile MI, US

B60L007/00

188/158000

A vehicle parking brake assembly is particularly useful as a driveline parking brake. The parking brake assembly is spring applied and electrically released. A mechanical spring operates to move an engaging portion into a braking position when the parking brake is applied. An electrically powered actuator operates to selectively move the spring against the bias of the spring to thereby release the parking brake.

2011031, Dec 29, 2011

Jun 29, 2010

12/825667

Michael Heaton - Rock Hill SC, US
Seth Claus - Charlotte NC, US
Dennis Roffe - Tega Cay SC, US
David Cessna - Tega Cay SC, US

SCHAEFFLER TECHNOLOGIES GMBH & CO. KG - Herzogenaurach

F16C 33/34

384568

A tandem roller bearing having circumferential inner and outer races each having first and second contact surfaces with convex profiles is provided. Rolling elements are arranged between the inner and outer races, each of the rolling elements having a concave profile corresponding to the convex profiles of a respective pairing of the first contact surfaces of the inner and outer races or of the second contact surfaces of the inner and outer races. A cage is arranged between the inner and outer races that separates and is guided by the rolling elements. The rolling elements include first and second sets of rolling elements having first and second axes of rotation that are arranged between the first and second contact surfaces of the inner and outer races, respectively. The first and second axes of rotation are inclined in a same direction with respect to a central axis of the inner race.

2022040, Dec 22, 2022

Jun 16, 2021

17/348829

- Herzogenaurach, DE
Michael Heaton - Rock Hill SC, US
Guihui Zhong - Charlotte NC, US
James Brown - Rock Hill SC, US
Daniel Wuerdinger - Troy MI, US

Schaeffler Technologies AG & Co. KG - Herzogenaurach

F16C 33/38
F16C 19/06

A bearing, including: an inner ring defining a first groove; an outer ring including a radially inner surface, the radially inner surface facing an axis of rotation of the bearing and defining a second groove and a third groove; a cage radially disposed between the inner ring and the outer ring; a plurality of balls retained by the cage, and disposed in the first groove, and in the second groove; and a preloaded resilient washer assembly including a rigid washer and a resilient washer including a radially outermost surface disposed in the third groove. The resilient washer urges the rigid washer away from the outer ring in an axial direction parallel to an axis of rotation of the bearing.

2022034, Oct 27, 2022

Apr 23, 2021

17/238292

- Herzogenaurach, DE
Daniel Wuerdinger - Troy MI, US
Michael Heaton - Rock Hill SC, US
Dennis Roffe - Fort Mill SC, US
James Brown - Rock Hill SC, US

Schaeffler Technologies AG & Co. KG - Herzogenaurach

F16C 33/78
F16C 33/32
F16C 19/06

A bearing, including: an inner ring defining a first groove; an outer ring including a radially inner surface, the radially inner surface facing an axis of rotation of the bearing, defining a second groove, and defining at least one third groove; a cage radially disposed between the inner ring and the outer ring; a plurality of balls retained by the cage, and disposed in the first groove, and in the second groove; an annular sleeve including a first portion disposed in the third groove; and a resilient element urging the outer ring and the annular sleeve away from each other parallel to the axis of rotation of the bearing.

2021028, Sep 16, 2021

Mar 16, 2020

16/820109

- Herzogenaurach, DE
Ronald Taylor - York SC, US
Guihui Zhong - Charlotte NC, US
Michael Heaton - Rock Hill SC, US

Schaeffler Technologies AG & Co. KG - Herzogenaurach

F16C 33/38
F16C 33/42

A bearing cage assembly is disclosed herein that includes a first cage half formed as a plastic cage and a second cage half formed as a metal shell. The first cage half includes a first base rim and a first plurality of arms extending axially from the first base rim. The second cage half includes a second base rim and a second plurality of arms extending axially from the second base rim. The second plurality of arms are each formed by a first flange and a second flange. The first flange and the second flange are spaced apart from each other in a radial direction to define a receptacle dimensioned to receive a respective one of the first plurality of arms. Free ends of the first flange and the second flange are crimped over to retain the first cage half with the second cage half.

2021028, Sep 16, 2021

Mar 13, 2020

16/818190

- Herzogenaurach, DE
Michael Heaton - Rock Hill SC, US
Dennis Roffe - Fort Mill SC, US

Schaeffler Technologies AG & Co. KG - Herzogenaurach

F16C 33/38
F16C 19/06

A bearing cage assembly is disclosed that includes two sub-assemblies. Both cage sub-assemblies include a shell half formed from plastic, and defining a plurality of rolling element pockets and openings. Each sub-assembly also includes a frame half formed from metal, and including a rim and a plurality of crossbars. The shell halves are overmolded with the frame halves. The first cage sub-assembly and the second cage sub-assembly are connected to each other via insertion of the crossbars into the openings of the other sub-assembly, such that free ends of the crossbars engage the other rim.

2021026, Aug 26, 2021

Feb 26, 2020

16/801850

- Herzogenaurach, DE
Guihui ZHONG - Charlotte NC, US
Michael HEATON - Rock Hill SC, US
Dennis ROFFE - Fort Mill SC, US

SCHAEFFLER TECHNOLOGIES AG & CO. KG - Herzogenaurach

F16C 33/38
F16C 19/06

A bearing cage includes a first annular body having a plurality of circumferentially arranged fingers that extending axially therefrom. Each of the fingers have a tab with a first arcuate engagement surface. A second annular body has a plurality of circumferentially arranged finger-receiving holes extending axially and configured to receive the fingers. Each of the holes have an associated second arcuate engagement surface configured to engage with the first arcuate engagement surface when the fingers are received in the holes to secure the first and second bodies together to form the bearing cage.

2017010, Apr 13, 2017

Oct 12, 2015

14/880662

- Herzogenaurach, DE
Michael HEATON - Rock Hill SC, US

SCHAEFFLER TECHNOLOGIES AG & CO. KG - Herzogenaurach

F16C 33/38
F16C 19/18

A cage for a rolling bearing assembly with optimized contact surfaces to reduce friction between the cage and the adjacent contact surfaces is disclosed. The rolling bearing assembly includes a radially inner bearing ring including a radially inner race defined on a radially inner rolling element facing surface, a radially outer bearing ring including a radially outer race defined on a radially outer rolling element facing surface, and a plurality of rolling elements supported to roll between the radially inner race and the radially outer race. The cage includes a first rim including a first rolling element guide surface facing a plurality of rolling elements. A first outer surface facing away from the first rolling element guide surface includes a first outward projection. In another embodiment two bearing assemblies are provided, and each of the bearing assemblies includes a cage with optimized contact surfaces.
