Michael R Lemmon Deceased415 Ridge Rd, Muncie, IN 47304

6491580, Dec 10, 2002

Sep 28, 2001

09/967158

Michael E. Lemmon - Albion IN, 46701
Charles M. Lemmon - Albion IN, 46701

F24F 710

454253, 138116, 138117, 2851241, 2851242

The present invention relates to a duct and ventilation system for livestock production buildings. The building comprises a plurality of containment rooms for livestock, a pit beneath the room, an attic above the rooms, a ventilation duct for each room and a ventilation house coupled to the pit. The containment rooms have slatted floors. The attic includes a vent. Each ventilation duct includes a manually actuable air flow control valve. The ventilation house includes an exhaust fan and is adapted to draw air through the vent and through the attic to one of the ventilation ducts and into one of the rooms through the slatted floor and out via the ventilation house. The building may include a manifold area adjacent the rooms and in fluid communication with the attic. Ventilation ducts comprise a laminar polymer sheet having a generally rectangular shape and forming a corner generally parallel to first and second side edges, a second laminar and planar polymer sheet having a first edge and a second edge, and a plurality of brackets. The first edge of the second sheet attaches to the first sheet such that the second sheet is substantially parallel to the corner.

8635974, Jan 28, 2014

Dec 23, 2009

12/646446

Michael E. Lemmon - Kendallville IN, US
Charles E. Lemmon - Albion IN, US

Whiteshire/Hamroc LLC - Albion IN

A01K 1/00

119448, 119493, 119500

A livestock production building includes an automatically controllable ventilation system which provides ventilation to livestock containment rooms. Incoming air may be heated, cooled and/or filtered, and is mixed and tempered before being delivered to livestock rooms. Substantially all exhaust air is filtered to mitigate environmental impact.

6321687, Nov 27, 2001

Jul 28, 1999

9/362383

Michael E. Lemmon - Albion IN
Charles M. Lemmon - Albion IN

Whiteshire/Hamroc LLC - Albion IN

A01K 100

119448

A duct and ventilation system for livestock production buildings. The building comprises a plurality of containment rooms for livestock, a pit beneath the room, an attic above the rooms, a ventilation duct for each room and a ventilation house coupled to the pit. The containment rooms have slatted floors. The attic includes a vent. Each ventilation duct includes a manually actuable air flow control valve. The ventilation house includes an exhaust fan and is adapted to draw air through the vent and through the attic to one of the ventilation ducts and into one of the rooms through the slatted floor and out via the ventilation house. The building may include a manifold area adjacent the rooms and in fluid communication with the attic. Ventilation ducts comprise a laminar polymer sheet having a generally rectangular shape and forming a corner generally parallel to first and second side edges, a second laminar and planar polymer sheet having a first edge and a second edge, and a plurality of brackets. The first edge of the second sheet attaches to the first sheet such that the second sheet is substantially parallel to the corner.
