Michael R Raleigh, 603309 Brockton Dr, Jefferson, MD 21755

7028807, Apr 18, 2006

Aug 26, 2003

10/648841

Michael Raleigh - Alexandria VA, US
James Galambos - Alexandria VA, US
Michael Bohnet - Herndon VA, US

BAE Systems Advanced Technologies, Inc. - Nashua NH

G01V 1/06
G01V 1/38
G01V 1/157
G01V 1/116

181119, 181118, 181110, 181120, 367147, 367171

A non-explosive acoustic source utilizes the combustion of aluminum and water to generate an acoustic pulse. The operation of the non-explosive acoustic source relies on a water/aluminum reaction to generate a burst pressure. The source may be deployed as a single charge or as one element of a multiple charge array and is configurable to explode at variable depths with variable energy levels. The inherent safety of the non-explosive acoustic source obviates the necessity for auxiliary safety features or procedures to protect against inadvertent explosion. As a result, the non-explosive acoustic source facilitates the implementation of sonic detection systems and reduces the operational costs associated with such systems.

7218571, May 15, 2007

Aug 30, 2004

10/929952

Michael Raleigh - Alexandria VA, US
Yeshayahu Goldstein - Gaithersburg MD, US
James Galambos - Alexandria VA, US

BAE Systems Advanced Technologies, Inc. - Nashua NH

H04K 3/00

367 1

An apparatus and method for magnetically generating an underwater high pressure pulse of sufficient strength to destroy underwater threats utilizes a pair of electrically conductive elements. The electrically conductive elements are arranged substantially parallel with each other and are separated by a gap. A pulse generator supplies an electrical pulse to at least one of the electrically conductive elements, which causes the generation of a magnetic repulsion force between the elements. The magnetic repulsion force causes one the electrically conductive elements to be displaced, thereby inducing a high pressure pulse in the liquid in which the pair of electrically conductive elements is submerged.

7305912, Dec 11, 2007

Dec 30, 2004

11/027755

Shyke Goldstein - Gaithersburg MD, US
Michael Raleigh - Alexandria VA, US
Michael Bohnet - Herndon VA, US
James Galambos - Alexandria VA, US
Mark Machina - Alexandria VA, US

BAE Systems Advanced Technologies, Inc. - Nashua NH

F41F 1/00

89 9, 89 8

An electrothermal gun uses an apparatus for generating high gas pressure. The apparatus includes a receiver having a combustion chamber for holding a propellant which produces a gas component and a particle component when the propellant undergoes an exothermic chemical reaction, and a flow passageway positioned downstream of the combustion chamber. An ignition mechanism causes the propellant contained in the combustion chamber to undergo the exothermic chemical reaction. A separator in the flow passageway substantially separates the particle component from the gas component in the flow passageway. The gun includes a barrel connected to the receiver and communicating with the flow passageway. By substantially stopping the particle component, namely metal oxide, from reaching the barrel, wear on the barrel is reduced.

8272327, Sep 25, 2012

Oct 22, 2009

12/604018

Mark H. Machina - Leesburg VA, US
Michael Raleigh - Alexandria VA, US
Kristopher P. Mount - Falls Church VA, US
Kenneth W. Mitchell - Fredericksburg VA, US
Michael A. Bohnet - Herndon VA, US

BAE Systems Information and Electronic Systems Integration Inc. - Nashua NH

F42B 10/06

102473

A system for firing multiple projectiles in a parallel or diverging manner is provided. The system can comprise tail-end portions of projectiles that add structure to a cartridge, provide for efficient combustion, allow projectiles to transition from a straight configuration in the cartridge to a splayed configuration in a chamber, and ensure complete evacuation of the chamber. The system can include a tail-end portion of a particular projectile with openings that distribute energy from combustion of an ignition charge, facilitating firing of multiple projectiles. A tail-end portion of a projectile can include a ball joint upon which the body portion of the projectile moves causing an angle between the body portion and the tail-end portion. A space can exist in the body portion adjacent to the ball joint to allow off-center shifting of the body portion with respect to the ball joint.

8430036, Apr 30, 2013

Aug 15, 2012

13/585868

Mark H. Machina - Leesburg VA, US
Michael Raleigh - Alexandria VA, US
Kristopher P. Mount - Falls Church VA, US
Kenneth W. Mitchell - Fredericksburg VA, US
Michael A. Bohnet - Herndon VA, US

BAE Systems Information and Electronic Systems Integration Inc. - Nashua NH

F42B 5/03

102473

A system for firing multiple projectiles in a parallel or diverging manner is provided. The system can comprise tail-end portions of projectiles that add structure to a cartridge, provide for efficient combustion, allow projectiles to transition from a straight configuration in the cartridge to a splayed configuration in a chamber, and ensure complete evacuation of the chamber. The system can include a tail-end portion of a particular projectile with openings that distribute energy from combustion of an ignition charge, facilitating firing of multiple projectiles. A tail-end portion of a projectile can include a ball joint upon which the body portion of the projectile moves causing an angle between the body portion and the tail-end portion. A space can exist in the body portion adjacent to the ball joint to allow off-center shifting of the body portion with respect to the ball joint.

4629975, Dec 16, 1986

Jun 19, 1984

6/640178

Ralph Fiorito - Bethesda MD
Michael Raleigh - Laurel MD

The United States of America as represented by the Secretary of the Navy - Washington DC

G01N 2700
G01K 108

324 713

An interceptive type electric probe for mapping the radial current density rofile of high energy and high current electron beams comprises an input sensor, an interface support connector and an output support connector. The entire structure of the electric probe is configured to closely approximate a coaxial transmission line of a predetermined impedance that is opened ended but yet shielded. The nature of the construction of the probe, in terms of materials and techniques, allows for survival thereof in high temperature and intense beam environments.

4586008, Apr 29, 1986

Nov 9, 1983

6/550091

Michael Raleigh - Laurel MD

H03H 102

333 19

A passive integrator capable of correctly providing outputs with risetimes as short as 250 ps. An outer conductor has coaxially mounted therein a short length of an inner conductor so as to constitute a very low impedance transmission line. The short length and low impedance of this transmission line cause it to behave as a capacitor. Electrostatically shielded resistors are connected to both ends thereof by a center conductor. Compensating capacitors coaxially mounted therewith may be employed.
