Michael F Santucci, 67625 Idaho Ave, Verona, PA 15147

7182283, Feb 27, 2007

Dec 17, 2004

11/016244

Michael T. Santucci - Akron OH, US

Engineering Consultants Group, Inc. - Akron OH

B02C 4/32

241 37, 2411013, 241117

A pulverizer monitoring system is applicable to at least one pulverizer having a rotatable bowl assembly, and at least one journal assembly having a grinding roll positioned proximal the rotatable bowl assembly, wherein the grinding roll is deflected by the feedstock raw material forced under the roll during rotation of the rotatable bowl assembly. A position sensor is mounted to the journal assembly to detect an amount of deflection of the grinding roll and generates a position signal, wherein a data module is associated with each pulverizer so as to receive the position signal. A calculation engine is linked to each data module for the purpose of analyzing the position signal and other operational signals associated with the pulverizer and generating at least one characteristic pulverizer condition report. A web-based server is linked to the calculation engine to provide network access to the characteristic report(s), either real-time or historical trends. A user interface is provided with either the calculation engine and the web-based server to allow the custom setting of alarms and/or formats for the output associated with the characteristic report(s).

8042736, Oct 25, 2011

Apr 23, 2009

12/428683

Michael Santucci - Akron OH, US
James Scavuzzo - Medina OH, US
Martin Z. Bazant - Lexington MA, US

Engineering Consultants Group, Inc. - Akron OH

G06K 5/00

235380, 235385

The invention provides a system of devices and a set of methods for accurately characterizing, tracking and controlling bulk material flows. Measurements of input material properties, dynamical measurements involving identifiable tags, and fast, discrete simulations are combined to predict and control the composition of bulk material exiting a container, such as a silo, bunker or hopper. In one embodiment, a system is provided for a coal-fired power plant where the properties of coal are assessed, then the coal is marked and tracked to provide the plant's operators improved control over the coal mixture and target bulk properties as it makes its way from a coal receiving station to delivery for combustion in a furnace.

4026419, May 31, 1977

Oct 29, 1975

5/626960

Michael Charles Santucci - Barberton OH

The Babcock & Wilcox Company - New York NY

B65G 700

214 1H

An illustrative embodiment of the invention provides a cost effective reuseable erection system for use in the erection and handling of pendant superheater modules of a steam generating system. Sections of the modules are attached to and enclosed in a simple supporting and stabilizing framework which may be detachably connected to a lift beam disposed in spaced relation and aligned longitudinally above the module section in the lateral plane through the center of gravity of the module - framework structure. This disposition of the lift beam enables a single lift line, attached to the lift beam at the longitudinal plane of the center of gravity of the module-framework-lift beam structure, to lift the structure during handling and erection. Further, since the lift beam is detachable and therefore not part of the supporting framework a substantial savings in framing material and shipping and storing fees is established.
