Inventors:
- Raynham MA, US
Joseph Capozzoli - Mount Laurel NJ, US
Raymond Schmitt - Havertown PA, US
Peter Fatone - Exton PA, US
Michael Brace - Lansdale PA, US
Eric Lui - Royersford PA, US
Benjamin Barrall - Lititz PA, US
Kenny Koay - West Chester PA, US
Steven Opsitnick - Newark DE, US
International Classification:
A61B 17/17
A61B 17/80
Abstract:
A screw guide includes a first end, a second end spaced from the first end, a guide body that extends from the first end to the second end, and a guide hole that extends through the guide body. The guide body includes a first guide surface and a second guide surface, the first guide surface defines a first opening of the guide hole, and the second guide surface is spaced from the first guide surface in a first guide direction. The second guide surface defines a second opening of the guide hole, the guide body includes a leg portion that extends from the second guide surface in the first guide direction such that the leg portion is spaced from the second opening in a second guide direction that is perpendicular to the first guide direction.
