Rene R Silva, 66Long Island City, NY

4306539, Dec 22, 1981

Jul 11, 1980

6/168690

Rene N. Silva - Ridgewood NJ

F23J 1100

126312

A heater venting system in which a draft hood which connects at its upper end to a chimney, which has an open lower end and which has an opening intermediate its upper and lower ends connected to the heater exhaust flue has its open lower end connected for gas flow to a chamber which is open to the building inside air at its upper end and which is connected at its lower end to air outside the building by a damper controlled duct to provide an inside air-outside air interface at, or above the lower end of the hood to restrict the flow of building inside air into the hood.

4012846, Mar 22, 1977

Jul 28, 1975

5/599331

Rene N. Silva - Ridgewood NJ

F26B 1700

34 57R

Apparatus for removing at least a portion of the liquid from a liquid-solid mixture in which the liquid-solid mixture is sprayed into one end of a substantially peripherally continuous, moving wall tube and a heated gas is caused to flow through the tube either in the same direction or the opposite direction as the flow of the liquid-solid mixture spray. The tube is formed by moving belts or is a rotatable hollow cylinder, and deposits on the wall of the tube are scraped from the wall by blades or knives. The tube is surrounded by an enclosing tube, and the separated solids, or liquid-solid mixture of lower liquid content, are received in a hopper or on moving belts below the first-mentioned tube from which such solids, or mixture, are removed. After passing through the first-mentioned tube, the gases are vented to the atmosphere or further processed. The apparatus may also be used to remove products of combustion from the gases.
