Robert E Boyer Deceased101 Patricia Ln, Prospect Heights, IL 60070

4798934, Jan 17, 1989

Apr 22, 1986

6/855077

Robert E. Boyer - Prospect Heights IL

H05B 100
H05B 300
B23K 304

219233

A hand-held electrically heated tool for applying heat to an object includes an elongated metallic tubular handle open at its forward and rear ends and having a plurality of raised relatively-spaced longitudinally extending vanes formed on its the inner surface and extending between the forward and rear ends thereof. An exposed metal electrical resistance heating element forming a wire tip is mounted in an insulator disposed in the forward end of the handle in engagement with the vanes with the tip extending forwardly of the handle. A spherically concave portion of the insulator reflects heat away from the handle. The vanes extend forwardly of the handle to form prongs spacing the insulator a distance from the forward end of the handle to allow exterior cooling air to enter air spaces defined by the vanes between the insulator and inner surface of the handle, flow the length of the handle, and exit through openings formed in the rear end of the handle by removal of the wall of the handle at discrete areas to expose the vanes and the air spaces therebetween. The outer surface of the handle is fluted to increase heat dissipation and enable comfortable gripping.

4657289, Apr 14, 1987

Aug 19, 1985

6/767136

Robert E. Boyer - River Grove IL

H02P 904
H02K 710

290 1R

An electrical power and signal generator and sensing device mountable on a rotatable body, such as a vehicle wheel, oribiting around its axis and using the rotation of the wheel to drive the generator through a friction drive.

4536668, Aug 20, 1985

Sep 13, 1982

6/417473

Robert E. Boyer - River Grove IL

H02K 710

310 75R

A vehicle-mountable electrical power generating mechanism and signal transmitter, combined to constitute a self-powered generating system mountable such as on a wheel to monitor and provide an indication of certain operating characteristics of the wheel, such as the pressure of the tire mounted thereon.

4539497, Sep 3, 1985

Apr 11, 1983

6/483710

Robert E. Boyer - River Grove IL

H02K 710

310 75R

An electrical generator utilizing a pendulum in the generator drive mechanism to provide a non-rotating reference whereby rotation of the wheel drives elements of the generator into rotation with respect to one another. The assembly is mounted in a wheel-mounted toroidal-shaped housing having a passage accommodating the vehicle axle to allow the unit to be mounted close inboard against the wheel or, alternatively, behind the wheel or within a brake system.
