Robert B Lopez, 59901 E Washington St UNIT 138, Colton, CA 92324

D360017, Jul 4, 1995

Jun 7, 1994

D/024066

Robert Lopez - Ontario CA

D23259

D353443, Dec 13, 1994

Oct 21, 1991

7/779582

Robert Lopez - Ontario CA

D23259

5156642, Oct 20, 1992

Aug 16, 1991

7/745745

Robert Lopez - Ontario CA

F16L 5518

137 15

This invention relates to a fluid distribution manifold, where the input piping is inserted in through the manifold's circular intake opening and into its cylindrical intake port. The manifold's intake port has an intake restraint rim on its inner surface in order to prevent the intake piping from being inserted too far into the manifold. In some embodiments, the manifold also has a glue trap located below the intake restraint rim, and of approximately the same dimensions and geometry as the intake restraint rim. The manifold's intake port leads to a cup- or parabola-shaped intake reservoir, where fluid is briefly housed prior to its distribution through several distribution output opening, and their respective distribution outlet ports. In some embodiments, the manifold's distribution outlet ports each possess an output restraint rim on the inner surface of each of the distribution outlet ports, to prevent the output piping from being inserted too far into the port. In a preferred embodiment, the manifold is constructed of polyvinyl chloride or acylonitrile-butadiene-styrene, and is used to distribute fluids, such as water and ozone, in spas and hydrotherapy baths.

5224844, Jul 6, 1993

May 14, 1991

7/699908

Robert Lopez - Ontario CA

F04B 1700
F04B 3504

4174231

This invention relates to an in-line and frame independent electric blower housing, with cylindrical walls or essentially nonparallel interior walls constructed of an elastomeric material, and which is thereby acoustically silenced and is also easily disassembled for maintenance. The blower housing consists of two halves and may be adapted to house a larger motor, through the fitting of an adapt or collar device between the two halves of the blower housing. The blower housing was designed for use in the spa industry, as an air blower, but has applications in other industries.

5391064, Feb 21, 1995

Oct 26, 1992

7/967677

Robert Lopez - Ontario CA

F04B 1700

41742314

This invention relates to an in-line and frame independent electric blower half-housing, with cylindrical walls or essentially nonparallel interior walls constructed of an elastomeric material, and which is thereby acoustically silenced and is also easily disassembled for maintenance. The blower half-housing consists of one piece. The blower half-housing was designed for use in the spa industry, as an air blower, but has applications in other industries.

D335532, May 11, 1993

Mar 27, 1991

7/676231

Robert Lopez - Ontario CA

D23383

5474102, Dec 12, 1995

Feb 14, 1994

8/195253

Robert Lopez - Ontario CA

A61H 3302

137271

This invention relates to a fluid distribution manifold, where the input piping is inserted in through the manifold's circular intake opening and onto its cylindrical input port. The manifold's intake opening leads through a cylindrical path to a closed terminal end. Along the inner manifold wall, there are arranged in a sequence, which may be in a straight line, a series of straight lines or rows, a spiral, or an alternating 90- or 180-degree arrangement, a number of distribution outlet openings and their respective ports, which may be barbed or ribbed on their outer surface. The manifold has the further utility of being expandable to larger sizes. This is achieved by removing the closed terminal end from one manifold and then inserting and connecting that open terminal end in through another manifold's circular intake opening and into its intake port. To achieve a more uniform fluid flow pressure at each of the distribution outlet ports, two or more manifold devices may be fitted and connected to intake piping which is fitted with a T-joint or Y-joint. In a preferred embodiment, the manifold is composed of acrylonitrile-butadiene-styrene, and is used to distribute air in spas and hydrotherapy baths.

D389245, Jan 13, 1998

Dec 20, 1995

D/048790

Robert Lopez - Ontario CA

2302

D24204
