Robert J Stang Deceased4015 Leavitt Dr NW, Warren, OH 44485

6354890, Mar 12, 2002

Mar 17, 2000

09/527837

Robert J. Adkins - Warren OH
Robert Stang - Warren OH
Robert L. Sten - Warren OH

Delphi Technologies, Inc. - Troy MI

H01R 13187

439843, 439851, 439859

A sleeve and post terminals combination, wherein a single piece sleeve terminal which is slidingly interfaced with a smooth surfaced post terminal for high current circuit applications. The sleeve terminal is formed from sheet metal stock, having an inner sleeve component and an outer sleeve component. The inner sleeve component includes three circumferentially spaced electrical contracts. The post terminal is configured to be snugly received by the inner sleeve component, wherein the three contacts are radially forced against the post terminal. The post terminal preferably has a bullet nose and has a smooth surface. In a preferred environment of operation, the post terminal is connected with a BEDC, and the sleeve terminal is connected with a high current capacity wire.

6358104, Mar 19, 2002

Jan 10, 2000

09/480069

James D. Daugherty - Brookfield OH
William G. Strang - Warren OH
Robert Stang - Warren OH
Christopher Adrian Margrave - Cortland OH

Delphi Technologies, Inc. - Troy MI

H01R 1311

439851

Disclosed herein is an electrical female terminal which comprises a direct current path between a contact region defined by a plurality of circumferentially spaced contact vanes formed as beams having opposite ends connected to terminal body portions and wherein each vane is twisted on its length to provide a radially inwardly directed contact on a beam that provides a torsional force component that increases normal forces for providing electrical contact without producing a commensurate increase in the force required to engage a pin within the contact region.

6416340, Jul 9, 2002

May 4, 2000

09/564280

Christopher E. Schaefer - Warren OH, 44485
John Kountz - Poland OH, 44514
Joseph A Finnerty - Warren OH, 44484
Robert Stang - Warren OH, 44486

H01R 2700

439224

A power connector system has a male member, a female member and a contact member. A cable is attached to the male member. The female member has a U-shaped channel. The contact member is U-shaped and is received in the channel. The side walls of the channel have outer edges defining an outer opening to the channel and end edges defining an end opening to the channel. The male member has a single blade which is insertable into the contact member either though the outer opening or through the end opening.
