Roger Bryan Simons, 576337 Jackson Lake Rd, Monticello, GA 31064

6745859, Jun 8, 2004

May 1, 2002

10/136588

Beverly Ann Simons - Davidson NC, 28036
Roger Larry Simons - Davidson NC, 28036

B62D 5104

180 191, 180 651, 280 4726, 280653

A powered wheel assembly for use in connection with a wheelbarrow includes in one embodiment a frame that includes support members, a wheel assembly that includes a wheel, an axle, and axle housing, and a pin for connecting the axle and axle housing, and a drive assembly that includes a primary gear drive and a final chain drive. Upon retrofit to an existing wheelbarrow, the powered wheel assembly permits an operator to selectively operate the wheelbarrow in a powered and non-powered mode of transport.

4903655, Feb 27, 1990

May 22, 1989

7/354749

Werner Vonderau - Backnang, DE
Hans Holderle - Freiberg, DE
Armin Speckens - Waiblingen, DE
Jurgen Wolf - Stuttgart, DE
Roger Simons - Virginia Beach VA

Andreas Stihl - Waiblingen

F02B 7700

123198C

The invention is directed to a membrane fuel pump for an internal combustion engine equipped with a membrane carburetor. The engine is that of a working apparatus and especially a handheld portable tool such as a motor-driven chain saw or the like. The membrane pump includes a drive chamber charged with the pressure inside the crankcase of the engine and a pump chamber separated from the drive chamber by a membrane. The pump chamber is connected at its suction end to a fuel tank via a first check valve and is connected to a pressure controller of the membrane carburetor at its pressure end via a second check valve. The pressure end of the membrane pump is connected with the suction end thereof via a bypass and a throttle is mounted in this bypass. With the throttle bypass between the pressure end and the suction end, the pumped volume is reduced at idle and the pump pressure is smoothed. Disturbances at the membrane carburetor are avoided.

2021006, Mar 4, 2021

Sep 3, 2020

17/011386

Roger Larry Simons - Davidson NC, US

B62B 3/12
B62B 5/00

A wheelbarrow with multiple wheels on a front axle is provided. The wheelbarrow includes a cargo carrying portion, two load carrying members supporting the cargo carrying portion, and a motor providing an output torque. The wheelbarrow further includes the front axle attached to the two load carrying members, a middle wheel attached to the axle and receiving the output torque from the motor, and two side wheels attached to the axle, one on either side of the middle wheel wherein the two side wheels each have a smaller diameter than the middle wheel.

2020035, Nov 12, 2020

Jul 20, 2019

16/517572

- Belleville MI, US
Roger Larry Simons - Davidson NC, US
Robert L. Nolff - Romulus MI, US

Century Fuel Products, LLC - Belleville MI

G05D 16/06
F02M 21/02
G05D 7/06

A system for controlling a gas fuel flow in a fuel delivery system includes an on-demand pressure regulator. The pressure regulator includes an internal diaphragm configured to provide the gas fuel flow from an outlet port of the pressure regulator within a desired pressure range and a cut-off valve selectively blocking the gas fuel flow through the pressure regulator.
