Scott M Murray, 4616820 County Road Cc, Holt, MO 64048

4950959, Aug 21, 1990

Mar 3, 1989

7/318703

Anders V. Beckrot - Laguna Beach CA
James C. Helling - Newport Beach CA
Scott V. Murray - Huntington Beach CA

LumiTech International, L.P. - New York NY

H05B 3702
H05B 4116
H05B 4124
H05B 3704

315219

A cassette light retrofit adapted to be received in a housing portion of an existing lighting fixture from which the light tubes and door frame with diffuser have been removed comprises an open cassette enclosure having a door frame and diffuser closing the enclosure; a lightable tubing array in the cassette enclosure; a power converter in the enclosure connected to energize the lightable array; and, said cassette door frame being attachable to the fixture housing portion to replace said fixture door frame with the cassette enclosure being in said housing. The power converter uses 8 windings with isolation to improve the tracking efficiency of the sensing windings for accurate high frequency power application for the load. Also, an A. C. winding permits dimming of the lamp load by filling in chunks of voltage deleted by the dimmer.

4993237, Feb 19, 1991

Sep 21, 1989

7/410690

James R. Bond - Vancouver, CA
Scott V. Murray - Huntington Beach CA

Heritage Ventures U.S., Ltd. - Las Vegas NV

F25D 310

62294

The structure of the present invention comprises a self-cooling container in which a segregating wall is used to divide the container into a beverage chamber and a cooling chamber, the latter having a reaction chamber mounted therein, which in a preferred embodiment is of an elongated cylindrical shape. The reaction chamber cylinder of the present invention provides an inverted funnel-shaped bottom surface for receiving the flow of beverage from the beverage chamber portion of the container through a feed-through at the bottom of the segregating wall thereof. The funnel leads to a flow tube which is positioned in axial alignment with the cylinder, preferably through the center thereof and defining an inner wall of the reaction chamber. The reaction chamber houses a combination of chemical materials separated by a readily broken sealing device from a selected volume of distilled water, which rfeleased into the chemical constituents, initiates an endothermic reaction which extracts heat from the beverage.

4940921, Jul 10, 1990

Dec 11, 1987

7/131752

James C. Helling - Newport Beach CA
Anders W. Beckrot - Laguna Beach CA
Scott V. Murray - Huntington Beach CA

LumiTech International, L.P. - New York NY

H05B 4126
H05B 4136
H01F 2728

315219

A miniature, light weight, high voltage, high frequency, high power output unique ballast and a unique sealable neon lamp in a light weight, light reflective box containing the ballast for use as one of a plurality of ceiling lamps. The ballast includes a transformer with a tuned secondary due to distributed capacitance, as a result of spaced apart first and second halves of the secondary winding, particularly wound in three separate sections of a bobbin fitted on the center leg of the transformer E--E core and tightly coupled to a center tapped primary winding on the center leg of the other section of the E-core. The section of the core are separated by a high dielectric spacer which also gaps the core when the sections are placed together. An asymetrical starting circuit prevents burnout of the alternate conducting FET switching device by insuring that only a selected one FET always starts first, and the unique bobbin and secondary winding prevents breakdown in the secondary high voltage winding.

2023006, Mar 2, 2023

Aug 27, 2021

17/459912

- Irvine CA, US
Scott V. Murray - Mission Viejo CA, US

G09F 7/18
F16B 47/00

A silicone edge graphic mountable to a window with suction cups is shown. The silicone edge graphic may have a frame where the suction cups are attached to the frame and offset from the frame so that the frame is not touching a mounting surface of the window or the wall of the window when mounted to mitigate damage to the window or wall. When the silicone edge graphic is mounted to the window, the frame may rest on a support surface, such as a window sill or the ground, to provide additional support for the weight of the silicone edge graphic.

2021007, Mar 11, 2021

Sep 10, 2019

16/566620

- Irvine CA, US
Scott V. Murray - Mission Viejo CA, US

G09F 13/04

A silicone edge graphic that is magnetically mountable to a wall is disclosed. No mechanical fasteners or adhesives are used to mount the silicone edge graphic to the wall. The back surface of the silicone edge graphic may have a non-marring configuration, so that the silicone edge graphic does not damage the wall. Additionally, a frame of the silicone edge graphic may be flexible enough to allow the user to remove the silicone edge graphic by peeling the silicone edge graphic off of the wall starting from one peripheral section or corner then progressive to the rest of the periphery. The magnets may also be positioned to reduce a force required to lift the section or corner of the silicone edge graphic off of the wall to begin peeling the silicon edge graphic off of the wall.

2020030, Oct 1, 2020

Mar 27, 2020

16/833097

- Kansas City KS, US
Scott A. Murray - Kansas City KS, US

E04F 21/165
B25G 3/34
B23K 9/007
B23K 9/028
B08B 1/00

A metal hand tool including a handle attached to a blade piece and method of construction. The blade piece includes a blade opposite an elongated tang. The handle is made up of two, welded, symmetrical handle halves, each handle half having an opening for receiving a hang hole piece and a notched distal end for forming a handle opening to receive the blade piece elongated tang. In an embodiment, the handle includes a curved distal end accommodating a curved welded connection between the blade piece and the handle. The hand tool further includes a hang hole piece configured for placement through the hang hole openings in the handle and for welded connection to the handle. In an embodiment, the elongated tang includes a hang hole opening through which the hang hole extends. Some embodiments further include one or more tang guide pieces welded to the interior of the handle.

2018032, Nov 15, 2018

Jul 25, 2018

16/045244

Scott A. Murray - Kansas City KS, US
Sun Xiaowei - Yongkang City, CN

E04F 21/02

A system for finishing surfaces with a finishing material includes a handle assembly with proximal and distal ends. A material reservoir is mounted on the handle distal and includes an inlet and an outlet. A material applicator tool is mounted on the reservoir and receives material from the reservoir outlet. A discharge mechanism includes an extendable-retractable component or linear actuator connected to the reservoir for discharging or reloading material. An alternative embodiment includes a lockable, compressible gas spring. Another alternative embodiment includes a rotating element driven by a reversible motor mounted on the handle assembly. The rotating element drives a discharge mechanism in a discharge direction of rotation, and reloads the reservoir in a reload direction of rotation. Multiple alternative embodiments of linear actuators are disclosed. An alternative embodiment includes a push-to-open valve mechanism.

2018008, Mar 29, 2018

Sep 29, 2017

15/721601

- Kansas City KS, US
Scott Murray - Kansas City KS, US

E04F 21/10

A system for finishing surfaces with a finishing material includes a handle assembly with proximal and distal ends. A material reservoir is mounted on the handle distal and includes an inlet and an outlet. A material applicator tool is mounted on the reservoir and receives material from the reservoir outlet. A discharge mechanism includes an extendable-retractable component connected to the reservoir for discharging or reloading material. An alternative embodiment includes a lockable, compressible gas spring. Another alternative embodiment includes a rotating element driven by a reversible motor mounted on the handle assembly. The rotating element drives a discharge mechanism in a discharge direction of rotation, and reloads the reservoir in a reload direction of rotation.
