Inventors:
- Cupertino CA, US
SungChang LEE - San Jose CA, US
Alan AN - Sunnyvale CA, US
Richard BLANCO - San Francisco CA, US
Andrew CHEN - Sunnyvale CA, US
Maxime CHEVRETON - Mountain View CA, US
Kyle B. CRUZ - Campbell CA, US
Walton FONG - San Jose CA, US
Nigel J. FUNGE - Redwood City CA, US
Ki Myung LEE - Cupertino CA, US
Cheng-I LIN - Emeryville CA, US
Kenneth H. MAHAN - San Jose CA, US
Alyssa C. RAMDYAL - Waterdown, CA
Nikhil SHARMA - San Jose CA, US
Eric SHI - Cupertino CA, US
Wei Guang WU - Palo Alto CA, US
International Classification:
H05K 5/06
H05K 5/00
H04B 1/3888
Abstract:
An electronic device with a sealing layer is disclosed. The sealing layer may include several enhancements designed to improve the overall sealing performance. For instance, the sealing layer may include an adhesive material and several particles embedded in the adhesive material. The embedded particles may include liquid-activated particles that respond to liquid exposure. In some instances, the liquid-activated particles absorb the liquid. Additionally, the liquid-activated particles may expand and fill/cover areas previously occupied by the sealing layer or another structure of the electronic device. Further, the liquid-activated particles may adhere to one or more structures of the electronic device, thereby providing the sealing layer with sealing properties. As a result of the absorption/expansion/adhesion properties of the liquid-activated particles, the electronic device may maintain a specified ingress protection rating even subsequent to some form of breakdown of the sealing layer or damage to the electronic device.
