Thomas J Provenzano, 69Kent Lakes, NY

6314343, Nov 6, 2001

Dec 23, 1999

9/471862

Don L. Adams - Fairfield CT
Thomas J. Provenzano - Stratford CT
Ari M. Novis - Rocky Hill CT
Ann Crowley - Zelienople PA

Sikorsky Aircraft Corp. - Stratford CT

B64C 1902

701 3

An aircraft flight mode selector assembly utilizes computer-generated menus and soft wired bezel keys to enable the use of a greater number of flight modes to be accessed in a smaller space than is presently possible with a flight mode selector consisting solely of conventional dedicated switches, switch indicator lights, and hard wired selector panel assemblies. Serial bus connections between the flight mode selector assembly and the flight control computer in the aircraft reduce the amount of wiring needed for the flight mode selector assembly, as compared to present protocol which utilizes dedicated wiring for each dedicated switch in the aircraft flight mode selector. The use of computer-generated displays and menus permits easy expansion of the flight mode selector assembly without the need to add additional switches and switch indicator lights. The inclusion of a display information look-up table in the processor controller, which table is separate from the software program in the controller, allows changes to the flight mode selector panel display to be made merely by changing the look-up table. The flight mode selector assembly also includes a pilot message display which is used to convey text messages to the pilot of the aircraft.
