Tim L Etchells, 5314045 Palatine Ave N, Seattle, WA 98133

7695437, Apr 13, 2010

Dec 29, 2004

11/027912

Jens U. Quistgaard - Seattle WA, US
Tim Etchells - Bothell WA, US
Gregory Paul Darlington - Snohomoish WA, US
Charles S. Desilets - Edmonds WA, US

Medicis Technologies Corporation - Bothell WA

A61B 8/00

600446, 600437, 600443, 600444, 600445, 601 2, 601 3, 601 4

A therapy head for use in HIFU procedures is described. The therapy head has an enclosure with a window, an energy applicator and a means of moving the energy applicator within the enclosure. The therapy head uses motors and actuators to move the energy applicator, usually an ultrasound transducer, inside the enclosure. A controller is provided either internally or externally that allows the therapy head to identify and distinguish locations where the therapy head should be to radiate energy into a patient. The controller uses the motors and actuators to move the energy applicator into the desired locations.

8337407, Dec 25, 2012

Dec 29, 2004

11/027498

Jens U. Quistgaard - Seattle WA, US
Tim Etchells - Bothell WA, US
Gregory Paul Darlington - Snohomoish WA, US
Charles S. Desilets - Edmonds WA, US

LipoSonix, Inc. - Hayward CA

A61B 8/00
A61N 7/00

600439, 601 2

A two-stage control system is disclosed being made of a first control means for providing command and control of a robotic arm, and a second control means for the control and movement of a therapy device, such as an ultrasound transducer. The therapy device is positioned within a therapy head. The therapy head is attached to the distal end of the robotic arm. The two-stage control system provides for a macro and micro level of control for the therapy device during a therapy procedure.

8480600, Jul 9, 2013

Oct 26, 2009

12/606129

Barry Friemel - Redmond WA, US
Jessica E. Parsons - Kirkland WA, US
Charles D. Emery - Issaquah WA, US
Gregory P. Darlington - Snohomish WA, US
Justin A. Reed - Seattle WA, US
Tim Etchells - Bothell WA, US

Mirabilis Medica Inc. - Bothell WA

A61B 8/00

601 2, 600439, 604 22

HIFU therapy to a desired tissue site is controlled based on detected changes in one or more characteristics of a received backscatter signal resulting from exposure of the tissue to HIFU or other interrogation signals. In one embodiment, the bloom of backscatter signals outward from a treatment region (e. g. , towards the HIFU transducer) is detected and monitored. Once the bloom reaches a predetermined location, treatment is stopped. Other signal characteristics such as angular distribution of frequency components in the backscatter signal, changes in reflection, power required to saturate a tissue characteristic, changes in attenuation and changes in a cumulative energy distribution function of the backscatter signal that change as a result of the application of HIFU power are also used to control the delivery of HIFU signals in accordance with other embodiments of the disclosed technology.

7993289, Aug 9, 2011

Dec 29, 2004

11/026519

Jens U. Quistgaard - Seattle WA, US
Tim Etchells - Bothell WA, US
Gregory Paul Darlington - Snohomoish WA, US
Charles S. Desilets - Edmonds WA, US

Medicis Technologies Corporation - Bothell WA

A61N 7/00

601 2, 601 3

Described is a system and method for the destruction of adipose tissue using an energy applicator such as a HIFU transducer. The system has a scan head containing an energy applicator, a mechanical arm for carrying the weight of the scan head, and a therapy controller such as a computer for controlling the operation of the scan head. The therapy controller may be part of a general purpose computer, and may be used as a robotic controller to automate the procedure. Methods are included for destroying adipose tissue in a quick, non-invasive manner.

2005015, Jul 14, 2005

Dec 30, 2003

10/750369

Jens Quistgaard - Seattle WA, US
Charles Desilets - Edmonds WA, US
Gregory Darlington - Snohomoish WA, US
Tim Etchells - Bothell WA, US

LipoSonix, Inc. - Bothell WA

A61B008/14

600459000

A disposable transducer seal designed to seal an open aperture of a transducer housing for a therapeutic ultrasound procedure. The seal has a membrane, a retainer and a mating device for locking in place with the transducer housing. The membrane is essentially transparent to ultrasound energy while being stretched taunt about the retainer.

2005015, Jul 14, 2005

Dec 30, 2003

10/750370

Tim Etchells - Bothell WA, US
Gregory Darlington - Snohomoish WA, US

LIPOSONIX, INC. - Bothell WA

A61B008/14

600459000

An apparatus for degassing a coupling fluid for use with a high intensity ultrasound system is disclosed. The apparatus has a fluid circuit having a vacuum chamber, a circulating pump, a vacuum pump and optional sensors for detecting one or more fluid parameters, such as dissolved gases. The coupling fluid may also serve as a coolant for a HIFU transducer.

2005018, Aug 25, 2005

Dec 29, 2004

11/027911

Jens Quistgaard - Seattle WA, US
Charles Desilets - Edmonds WA, US
Tim Etchells - Bothell WA, US
Gregory Darlington - Snohomoish WA, US

LipoSonix, Inc. - Bothell WA

A61B005/05

600424000

A position tracking device is disclosed combining one or more optical sensors in a housing with a medical device. The medical device may be an insertion device or one that produces radiant energy. The device may utilize an on-board processor or an external processor to track position data generated by the optical sensors and correlate the treatment regime of the medical device. Alternative embodiments and methods of use are also described.

2005019, Sep 1, 2005

Dec 30, 2003

10/751344

Jens Quistgaard - Seattle WA, US
Tim Etchells - Bothell WA, US
Gregory Darlington - Snohomish WA, US
Charles Desilets - Edmonds WA, US

LIPOSONIX, INC. - Bothell WA

B25J009/00

901009000

An apparatus for precise positioning of a medical device is disclosed. The apparatus comprises a base, an articulating arm, a position sensor and a means for load balancing. The apparatus may also include a robotic driver and an additional rhythmic motion sensor. The apparatus is used to carry a therapy head for a medical procedure requiring precise positioning of a therapy head, precise movement of a therapy head, or use of a therapy head over a patient body for an extended period of time.
