Walter A Boyce Deceased15014 Anns Choice Way, Warminster, PA 18974

5747919, May 5, 1998

Jun 28, 1996

8/671890

Harish F. Gandhi - Morgantown WV
Walter A. Boyce - Fairmont WV
David R. Woodward - Morgantown WV

Philips Electronics North America Corporation - NY NY

H01J 560

31331801

An electric lamp includes a hybrid skirted lamp base including a plastic skirt portion and a metallic skirt portion having one end portion molded in said plastic skirt portion and a second end portion secured to the lamp envelope. The metallic skirt portion improves structural integrity and provides some thermal isolation from the lamp envelope allowing the use of a lower temperature plastic for the plastic skirt portion. The plastic skirt portion includes a weldless and solderless lamp base. A lamp cap contact includes a rigid shank received in a clamping bore of the plastic skirt portion. The diameters of the bore and shank and the elasticity of the bore wall are selected so that a conductive lead of the lamp is securely clamped between the shank and the bore wall when the shank is fully received in the bore. In a favorable embodiment, the lead has a free end extending in the direction of insertion of the shank into the bore, which avoids the lead wire from being pushed out of the bore.

5117156, May 26, 1992

Dec 6, 1990

7/623138

Thomas O. Leyh - Bridgeport WV
Walter A. Boyce - Fairmont WV

North American Philips Corp. - New York NY

H01J 744
H01J 1346

315 73

A rapid start fluorescent lamp having an improved hot restarting time. The lamp includes the standard envelope and end cap through which electrical connection is made by conductive feedthroughs which extend through the lamp stem to the interior of the lamp. One of the feedthroughs is connected to the cathode, and the other is connected to the leads of a fuse element which is contained within an envelope to isolate the fusible element from the lamp environment. A thermally activated bimetallic element is disposed across the leads of the fuse. The other lead of the fusible element is connected to the other end of the cathode. When the bimetal element is cold, it will bridge the connection between the other feedthrough to the other end of the cathode to permit rapid starting. When the bimetal heats up, the connection of both ends of the cathode to the heating current is broken. The location of the bimetallic element within the lamp envelope but not in the fuse container permits it to open and close more rapidly.

5493170, Feb 20, 1996

Sep 9, 1994

8/303993

Jack R. Sheppard - Fairmont WV
David R. Woodward - Morgantown WV
James A. Cinalli - Fairmont WV
Douglas W. Shriver - Fairview WV
Walter A. Boyce - Fairmont WV
Edmund R. Kern - Lewiston ME

Philips Electronics North America Corporation - New York NY

F21V 700
H01J 516

313113

A reflector lamp having a lens of vitreous material fused to a reflector body of vitreous material. An inner reflector surface of the reflector body includes a reflective coating having a first coating portion extending from the rim of the reflector body and a second coating portion extending from a location spaced from the rim towards a basal end of the reflector body. The second coating portion is a layer of silver and the first coating portion is a layer of material other than silver, such as aluminum, having a higher resistance to damage by high heat in the rim area during fusing of the lens to the reflector body. Higher efficacies are achieved with the silver layer spaced from the rim than with silver covering the entire reflector surface.

5789847, Aug 4, 1998

Oct 24, 1995

8/547768

David R. Woodward - Morgantown WV
Walter A. Boyce - Fairmont WV
Jack R. Sheppard - Fairmont WV

Philips Electronics North America Corporation - New York NY

H01J 516
F21V 700

313113

A reflector lamp having a lens of vitreous material fused to a reflector body of vitreous material. An inner reflector surface of the reflector body includes a reflective coating having a first coating portion extending from the rim of the reflector body and a second coating portion extending from a location spaced from the rim towards a basal end of the reflector body. The second coating portion is a layer of heat-treated silver having a uniform, whitish non-metallic appearance and being diffusely reflective. The first coating portion is a layer of material other than silver, such as aluminum, having a higher resistance to damage by high heat in the rim area during fusing of the lens to the reflector body.
