Walter J Gross DeceasedStamford, CT

6762430, Jul 13, 2004

Dec 5, 2002

10/310560

Edgar Alzner - Garden City NY
Stephen Zamprelli - Bardonia NY
Tom Lloyd - New Hyde Park NY
Walter Gross - Massapequa NY

Air Techniques, Inc. - Hicksville NY

G03C 516

250584, 250589, 378174

An imaging plate guide formed in different configurations corresponding to the various intraoral dental plate sizes, which in turn correspond to the dental intraoral film sizes commonly referred to as sizes 0 through 4, the imaging plate guides dedicated to intraoral imaging providing for guides for each plate size so that a desired array of feed width guides can be positioned on the scanner for scanning the intraoral plates and which scan extraoral imaging plates as well. The embodiment of the imaging plate guides provides not only for interchangeability with respect to the intraoral plate size, but also allows for the feeding of extraoral imaging plates without the need to remove the intraoral plate guides. The size 4 is not specifically described, but is analogous to the other sizes as would be obvious to one skilled in the art.

7048237, May 23, 2006

Apr 2, 2004

10/817474

Henry Hubner - Amityville NJ, US
Walter Gross - Massapequa NY, US

Air Techniques, Inc. - Hicksville NY

F21V 21/00

248121, 2482184

These and other objects of the present invention are achieved by an improved mounting assembly for a dental x-ray assembly comprised of a base plate member having outwardly-extending wall portions defining a U-shaped chamber along a longitudinal axis thereof and having upper threaded orifices and lower threaded orifices having axis perpendicular to the longitudinal axis of the base plate member and wherein a bearing block member is mounted with the U-shaped chamber for rotation by screw members threaded within the upper threaded orifices after mounting of the base plate member to a vertical support member in a vertical plane in a plane perpendicular to the vertical support member and wherein the block member is secured in the base plate member by locking means disposed in a lower threaded orifice once the bearing block is adjusted to a point eliminating any swinging of the dental x-ray assembly.

7048439, May 23, 2006

Apr 6, 2004

10/818913

Henry Hubner - Amityville NY, US
Walter Gross - Massapequa NY, US

Air Techniques, Inc. - Hicksville NY

A61B 6/14
H05G 1/02
A47F 5/00

378191, 378197, 378196, 24828851

These and other objects of the present invention achieved by adjustable linkage mounting member for shaft members associated with articulating positioning arm members of a dental x-ray assembly wherein each adjustable linkage mounting member is comprised of a housing member mounted within a chamber thereof for receiving a shaft member of a positioning arm member and having a brake shoe disposed in the chamber in frictional contact with the shaft member and wherein frictional contact is adjustable in response to a threaded member disposed in the chamber.

7061003, Jun 13, 2006

Jan 31, 2003

10/356204

Edgar Alzner - Garden City NY, US
Stephen Zamprelli - Bardonia NY, US
Eddy Paultre - West Hempstead NY, US
Walter Gross - Massapequa NY, US

Air Techniques, Inc. - Hicksville NY

G01N 23/04

250588, 250581, 250580

An erasure assembly for imaging plates comprised of a cover member and a base member, the cover member in the form of an inverted rectangular tray having a plurality of light sources and reflective sources mounted therein behind a diffuser glass member, the base member, complimentary with the cover member having a support area for the placement of imaging plates on their non-reactive surface, their photo-stimulable surface facing upwardly, the cover member closed upon the base member and there being a control means to activate the light sources for a time sufficient to erase the retained images on the photo-stimulable surface of the image plates.

7259385, Aug 21, 2007

Jun 20, 2005

11/155365

Edgar Alzner - Garden City NY, US
Stephen Zamprelli - Bardonia NY, US
Eddy Paultre - West Hempstead NY, US
Walter Gross - Massapequa NY, US

Air Techniques, Inc. - Melville NY

G01N 23/04

250588, 250581, 250580

An erasure assembly for imaging plates comprised of a cover member and a base member, the cover member in the form of an inverted rectangular tray having a plurality of light sources and reflective sources mounted therein behind a diffuser glass member, the base member, complimentary with the cover member having a support area for the placement of imaging plates on their non-reactive surface, their photo-stimulable surface facing upwardly, the cover member closed upon the base member and there being a control means to activate the light sources for a time sufficient to erase the retained images on the photo-stimulable surface of the image plates.

7348588, Mar 25, 2008

Oct 10, 2006

11/545616

Edgar Alzner - Garden City NY, US
Walter Gross - Massapequa NY, US

Air Techniques, Inc. - Melville NY

G03B 42/08

250589, 250580, 250581, 250582, 250584, 250588, 378181

These and other objects of the present invention are achieved by an apparatus and process for evaluating an image-wise exposed storage film positioned about a cylindrically-shaped member and linearly passed a cylindrically-shaped slot for interrogation by a light beam wherein a processing assembly is co-axially disposed within a processing chamber formed by the cylindrically-shaped member and wherein the processing assembly includes a plate member disposed for rotation in a plane perpendicular to the axis of the processing chamber and having a pentaprism and a fluorescence light sensor positioned proximate a contact point of the interrogating light beam with the storage film and further including converting electronics for the thus generated fluorescence light wherein after interrogation, the storage film is immediately restored in the same apparatus for subsequent reuse.
