Inventors:
Warren H. McLeod - Brick NJ
International Classification:
E01C 520
E01C 900
Abstract:
A plurality of rigid bars, made of wood, plastic or other material, are joined together to form an articulated assembly. A rope is threaded through bores formed in the bars. Spacers are placed over the rope between the bars. Ends of the spacers can be angled for inclining, declining or flat arrangements of adjacent bars. In the alternative, ends of spacers can be rounded and received in a rounded depression of the bore. In an alternate embodiment, flexible interlocking elements are connected to adjacent bars. Interlocking elements can have engaging male and female portions or can be screwed together. Each male and female portion can pass through a plurality of bars. When laid flat over a surface, the articulated assembly may be used as a support that forms a deck, walkway, or similar structure. Other uses of the assembly include a latticework, a barrier and a vertical support.
