Peng Zheng, 42Mason, OH

2022038, Dec 8, 2022

Nov 26, 2019

17/778278

- Franklin Lakes NJ, US
Peng Zheng - Chandler AZ, US

Bard Peripheral Vascular, Inc. - Franklin Lakes NJ

A61B 17/22
A61B 17/32

An ultrasonic probe assembly includes a handle configured to be handheld, and has a housing that defines a chamber. A carriage is slidably coupled to the housing. The carriage has an operator arm configured to be operable by a user to move the carriage between a first position and a second position. An ultrasonic catheter has a catheter sheath and an ultrasonic core wire. The ultrasonic catheter has a proximal end portion and a distal end portion. An ultrasonic transducer is positioned in the chamber of the housing. The ultrasonic transducer is connected to the proximal end portion of the ultrasonic catheter, and the ultrasonic transducer is connected to the carriage. The ultrasonic transducer is configured to longitudinally move in the chamber of the housing between a retracted position and an extended position coincident with a corresponding longitudinal movement of the carriage.

2021026, Sep 2, 2021

Jul 12, 2019

17/260204

- Franklin Lakes NJ, US
Peng Zheng - Chandler AZ, US
Sima Jalaleddine - Phoenix AZ, US
Joceline D. Cooks - El Mirage AZ, US
Jeremy B. Cox - Salt Lake City UT, US

Bard Peripheral Vascular, Inc. - Franklin Lakes NJ

A61M 39/02
A61M 39/04

Disclosed herein is an implantable port and an implantable port-detecting device (“IPDD”). The implantable port includes a housing and a septum over a portion of the housing. At least one of the housing or the septum incorporates a contrast agent for locating the septum of the implantable port when the implantable port is implanted in a patient. The IPDD includes a light source, a light detector, and a display configured to display a presence of the implantable port. The light source is configured to emit light in a near-infrared (“NIR”) range of wavelengths as incident light for absorption by the contrast agent. The light detector is configured to detect light in the NIR range of wavelengths including luminescent light emitted by the contrast agent. The display is configured to display a presence of the implantable port when the luminescent light from the contrast agent is detected by the light detector.

2021010, Apr 15, 2021

Dec 22, 2020

17/131073

- Franklin Lakes NJ, US
Michael A. Randall - Gilbert AZ, US
Peng Zheng - Chandler AZ, US
Dean M. Addison - Victoria, CA
Bryan A. Matthews - Saanichton, CA

A61B 8/00
A61B 8/08

An ultrasound imaging system includes an interventional medical device having a first tracking element that generates tip location data based on an EM locator field. An ultrasound probe has an ultrasound transducer mechanism and a second tracking element. The ultrasound transducer mechanism has an active ultrasound transducer array that generates two-dimensional ultrasound slice data at any of a plurality of discrete imaging locations within a three-dimensional imaging volume. The second tracking element generates probe location data based on the EM locator field. A processor circuit is configured to execute program instructions to generate an ultrasound image for display, and is configured to generate a positioning signal based on the tip location data and the probe location data to dynamically position the active ultrasound transducer array so that the two-dimensional ultrasound slice data includes the distal tip of the interventional medical device.

2020034, Nov 5, 2020

Jul 22, 2020

16/935637

- Flanklin Lakes NJ, US
Andrzej J. Chanduszko - Chandler AZ, US
Michael Randall - Gilbert AZ, US
Peng Zheng - Chandler AZ, US

A61B 17/22

An apparatus for performing an endovascular procedure. The apparatus includes an ultrasonic catheter supporting a first inflatable balloon. The apparatus includes an ultrasonic wave guide associated with the ultrasonic catheter. The ultrasonic wave guide includes a fluid lumen. The ultrasonic wave guide has a proximal portion and a distal portion. The apparatus includes an ultrasonic transducer having a transducer horn. The proximal portion of the ultrasonic wave guide is crimped directly onto the transducer horn. The ultrasonic transducer is configured to vibrate the ultrasonic wave guide at an ultrasonic frequency, and the ultrasonic wave guide is configured to transmit the ultrasonic frequency from the ultrasonic transducer to the distal portion.

2020026, Aug 27, 2020

Sep 29, 2017

16/649902

- Franklin Lakes NJ, US
Peng Zheng - Chandler AZ, US

A61B 34/20
A61B 17/22
A61B 8/08
A61B 8/00

A vascular occlusion treatment system includes an ultrasound imaging system having an imaging control circuit communicatively coupled to an ultrasound imaging probe and to a display screen, and an ultrasonic vibration system having an ultrasonic generator operatively coupled to a medical ultrasonic object, such as an ultrasonic catheter. The ultrasonic catheter has a corewire with a distal tip. The ultrasonic generator has a generator control circuit that alternatingly switches between an ultrasonic work frequency and a tracking frequency. The generator control circuit sends a notification to the imaging control circuit when the generator control circuit has switched from the ultrasonic work frequency to the tracking frequency. The imaging control circuit responds by initiating a search in an ultrasound imaging space to locate the distal tip that is vibrating at the tracking frequency, and indicating a location of the distal tip in the ultrasound image displayed on the display screen.

2020024, Aug 6, 2020

Apr 8, 2020

16/842930

- Franklin Lakes NJ, US
Michael A. Randall - Gilbert AZ, US
Peng Zheng - Chandler AZ, US
Samuel J. Radochonski - San Francisco CA, US
Dean M. Addison - Victoria, CA
Bryan A. Matthews - Saanichton, CA
Jeffery L. Addison - Victoria, CA

A61B 8/08
A61B 8/00
G06T 7/215

A method of generating a 3D ultrasound image includes acquiring a 3D volumetric data set corresponding to a 3D imaging volume of an ultrasound probe in a 3D detection volume; acquiring a position of the ultrasound probe with respect to the 3D detection volume; acquiring a position of an interventional medical device with respect to the 3D detection volume; determining a position of the interventional medical device relative to the 3D imaging volume of the ultrasound probe; determining an interventional medical device-aligned plane that intersects with a longitudinal axis of the interventional medical device; extracting a texture slice from the 3D imaging volume for a corresponding interventional medical device-aligned plane positional and rotational orientation; mapping the texture slice onto the interventional medical device-aligned plane; and rendering the interventional medical device-aligned plane as a 3D ultrasound image and displaying the rendered 3D ultrasound image on a display screen.

2020019, Jun 25, 2020

Apr 20, 2018

16/608767

- Tempe AZ, US
Andrzej J. Chanduszko - Chandler AZ, US
Long Chen - Tucson AZ, US
Kim R. Ligouri - Tempe AZ, US
Lenny Lopez - Tucson AZ, US
Genevieve Messina - Tucson AZ, US
Peng Zheng - Chandler AZ, US

A61M 39/02

Disclosed is an implantable medical device such as a port assembly including a catheter lock and one or more unique device identifiers (“UDIs”) of the catheter lock. The catheter lock is configured to fit over an end portion of a catheter over an outlet stem extending from a portion of the implantable medical device such as housing of a port. The one or more UDIs embedded in the catheter lock include machine-readable identification data for the implantable medical device. Also disclosed is a system including the implantable medical device and instructions stored in a memory of a computing device for execution by one or more processors. Methods related to the foregoing are additionally disclosed.

2019029, Sep 26, 2019

Jun 11, 2019

16/437138

- Franklin Lake NJ, US
Peng Zheng - Chandler AZ, US
Chad Van Liere - Phoenix AZ, US

A61B 17/22
A61M 25/09
A61M 25/00
A61B 17/32

A system including a console and a catheter assembly. The console may include an ultrasound-producing mechanism configured to convert an electric current into a vibrational energy. The console also may include a driving-parameter modifier configured to modify driving parameters to selectively provide one or more output modes for the vibrational energy. The catheter assembly may include a sheath including a sheath lumen and a core wire at least partially disposed within the sheath lumen. The core wire may include a proximal portion and a distal portion of the core wire, wherein the proximal portion of the core wire is coupled to the ultrasound-producing mechanism. A working length of the distal portion of the core wire beyond the sheath may be configured for longitudinal, transverse, or longitudinal and transverse displacement in accordance with the one or more output modes for the vibrational energy to effect different intravascular lesion-modification procedures.
