Wayne L Worrell, 87328 Conshohocken State Rd, Penn Valley, PA 19072

4428770, Jan 31, 1984

Feb 23, 1982

6/351473

Wayne L. Worrell - Narberth PA
Qing-Guo Liu - Philadelphia PA

University Patents, Inc. - Norwalk CT

G01N 2758
C04B 3548
C04B 3551

75 45

Materials, methods and articles for the electrochemical determination of sulfur and carbon in fluids are provided. In accordance with a preferred embodiment, an electrolyte is furnished comprising a solid solution of an oxide of either zirconium, thorium or hafnium together with an oxide of an element of groups IIA or IIIB of the periodic table of the elements together with a sulfide or carbide of an element of groups IIA or IIIB of the periodic table. Processes employing such electrolytes together with articles incorporating them are also contemplated.

5298235, Mar 29, 1994

Dec 16, 1991

7/808432

Wayne Worrell - Narberth PA
Peter K. Davies - Yardley PA

The Trustees of The University Of Pennsylvania - Philadelphia PA

H01M 810

429 33

Single-component bodies useful in fuel cells and other electrochemical devices are provided. In preferred embodiments, the single-component bodies comprise an anodic region at a first side, a cathodic region at a second, non-adjacent side, and an oxygen ion-conducting region substantially free from anodic or cathodic character disposed between said anodic and cathodic regions. The single-component bodies comprise either transition metal perovskites or oxide electrolytes such as yttria-stabilized zirconia doped with multivalent cations.

6251473, Jun 26, 2001

May 12, 1999

9/310432

Conghua Wang - Wayne PA
Wayne L. Worrell - Narberth PA

The Trustees of the University of Pennsylvania - Philadelphia PA

B05D 512

4271263

A method for fabrication of solid ceramic thin films in which a porous or dense supporting substrate is spray coated with an oxide powder/solid suspension to form a coated supporting substrate. The coated supporting substrate is then sintered at an elevated temperature to form a solid ceramic thin film on the supporting substrate.

5518830, May 21, 1996

May 12, 1995

8/440544

Wayne Worrell - Narberth PA
Ping Han - Monroeville PA
Yoshiharu Uchimoto - Drexel Hill PA

The Trustees of the University of Pennsylvania - Philadelphia PA

H01M 810

429 31

Single-component bodies useful in fuel cells and other electrochemical devices are provided. In preferred embodiments, the single-component bodies comprise an anodic region at a first side, a cathodic region at a second, non-adjacent side, and an oxygen ion-conducting region substantially free from anodic or cathodic character disposed between said anodic and cathodic regions. The single-component bodies comprise oxide electrolytes such as yttria-stabilized zirconia doped with multivalent cations such as titanium or terbium.

4627892, Dec 9, 1986

Feb 22, 1985

6/704385

Wayne L. Worrell - Narberth PA
Qing-Guo Liu - Philadelphia PA

University Patents, Inc. - Norwalk CT

G01N 2758

204 1T

Improved electrochemical sensors are provided through isostatic processing techniques. Improved electrochemical sensors, especially those suitable for use in metallurgical melts, having, at once, long-term stability, improved sensitivity, and improved physical properties including thermal shock resistance are provided. In accordance with a preferred embodiment, unitary bodies comprising the sensing electrolyte and a source of reference potential are fabricated through isostatic processing techniques. Methods for the preparation of these improved sensors together with methods for the improvement of sensing, especially of oxygen in metallurgical melts are also disclosed.

5112456, May 12, 1992

Dec 12, 1989

7/449781

Wayne Worrell - Narberth PA
Qingguo Liu - Bejing, CN
Yuhua Tang - Bejing, CN

Trustees of the University of Pennsylvania - Philadephia PA

G01N 27411

20415318

Electrochemical sensors are provided having improved sensitivity, stability and dirability. In accordance with preferred embodiments, such sensors comprise protective sheath means having at least one opening. Within the sheath and sealed thereto at the opening is a sensing body comprising metal oxide and an oxide from group IIA or IIB of the periodic table. Reference electrode means are also provided. Methods for monitoring the concentration of a species in a melt are also provided.

4301221, Nov 17, 1981

Dec 7, 1979

6/101134

Wayne L. Worrell - Narberth PA

University Patents, Inc. - Norwalk CT

H01M 458

429218

A battery is provided in which the anode contains an alkali metal in a high state of thermodynamic activity; the cathode comprises a partially alkali metal-intercalated chalcogenide of the formula A. sub. y MZ. sub. x wherein A is an alkali metal more electropositive and larger than the anode alkali metal, M is a transition metal of Group IV or V, x is a numerical value of from about 1. 8 to about 2. 1, y is a numerical value of from about 0. 01 to about 1 and Z is sulfur, selenium or tellurium; and the electrolyte comprises ions of the anode metal in a medium which is compatible with the anode and cathode allowing transport of the ion from anode to intercalate into the cathode. In the discharged state the battery includes a cathode characterized by the presence of A'. sub. z A. sub. y MZ. sub. x in which A' is alkali metal more electronegative than A and z is a numerical value in the range 0

4288508, Sep 8, 1981

Dec 4, 1979

6/100043

Wayne L. Worrell - Narberth PA

University Patents, Inc. - Norwalk CT

H01M 458

429218

A battery is provided in which the anode contains an alkali metal in a high state of thermodynamic activity; the cathode comprises a partially alkali metal-intercalated chalcogenide of the formula A. sub. y MZ. sub. x wherein A is an alkali metal more electropositive and larger than the anode alkali metal, M is a transition metal of Group IV or V, x is a numerical value of from about 1. 8 to about 2. 1, y is a numerical value of from about 0. 01 to about 1 and Z is sulfur, selenium or tellurium; and the electrolyte comprises ions of the anode metal in a medium which is compatible with the anode and cathode allowing transport of the ion from anode to intercalate into the cathode. In the discharged state the battery includes a cathode characterized by the presence of A'. sub. z A. sub. y MZ. sub. x in which A' is alkali metal more electronegative than A and z is a numerical value in the range 0
